Page 34 - Catalogo DHISA 2020-2021

CARBURO
CORTE

CORTADOR CON RADIO EN LAS ESQUINAS CORTADOR VERTICAL MULTI-USO FRACCIONAL A 90°
IP Medida Radio IP Medida
211-402-1 1/8" 0.020 214-302-1 1/8"
211-412-1 3/16" 0.020 214-304-1 3/16"
211-422-1 1/4" 0.020 214-306-1 1/4"
211-433-1 5/16" 0.030 214-308-1 5/16"
211-444-1 3/8" 0.045 214-310-1 3/8"
211-454-1 1/2" 0.045 214-314-1 1/2"
33

CORTADOR VERTICAL DE DESBASTE DE CARBURO C/TIALN Brocas de carburo
IP Diámetro Corte Diámetro Zanco Largo Corte Largo Total N. de Filos
433-202-1 1/4" 3/4" 1/4" 2-1/2" 3
433-204-1 5/16" 3/4" 5/16" 2-1/2" 3
433-206-1 3/8" 7/8" 3/8" 2-1/2" 3
433-208W-1 1/2" 1" 1/2" 3" 4
433-210W-1 5/8" 1-1/4" 5/8" 3-1/2" 4
433-212W-1 3/4" 1-1/2" 3/4" 4" 4
433-214W-1 1" 1-1/2" 1" 4" 5

BROCA DE CARBURO SÓLIDO MILIMETRICA
IP Diámetro Diámetro Largo Largo
Corte Zanco Corte Total
BROCA DE CARBURO SÓLIDO FRACCIONAL 601-024 1 1 5/8" 1.1/2"
Diámetro Diámetro Largo Largo
IP 601-042 1.5 1.5 3/4" 1.1/2"
Corte Zanco Corte Total
601-046 1/16" 1/16" 3/4" 1.1/2" 601-062 2 2 7/8" 1.3/4"
601-080 2.5 2.5 1" 2"
601-074 3/32" 3/32" 1" 2"
601-100 3 3 1.1/4" 2.1/4"
601-090 7/64" 7/64" 1.1/4" 2.1/4"
601-110 3.5 3.5 1.3/8" 2.1/2"
601-104 1/8" 1/8" 1.1/4" 2.1/4"
601-130 4 4 1.3/8" 2.1/2"
601-114 9/64" 9/64" 1.3/8" 2.1/2"
601-146 4.5 4.5 1.5/8" 2.3/4"
601-126 5/32" 5/32" 1.3/8" 2.1/2"
601-164 5 5 1.3/4" 3"
601-140 11/64" 11/64" 1.5/8" 2.3/4"
601-180 5.5 5.5 1.3/4" 3"
601-154 3/16" 3/16" 1.5/8" 2.3/4"
601-192 6 6 2" 3.1/4"
601-170 13/64" 13/64" 1.3/4" 3"
601-202 6.5 6.5 2" 3.1/4"
601-182 7/32" 7/32” 1.3/4” 3"
601-214 7 7 2.1/8" 3.1/2"
601-190 15/64" 15/64" 2" 3.1/4"
601-226 7.5 7.5 2.3/8" 4"
601-200 1/4" 1/4" 2" 3.1/4"
601-234 8 8 2.3/8" 4"
601-232 5/16" 5/16" 2.3/8" 4"
601-244 8.5 8.5 2.3/8" 4"
601-262 3/8" 3/8" 2.3/4" 4.1/4"
601-252 9 9 2.3/4" 4.1/4"
601-286 7/16" 7/16" 2.7/8" 4.1/2"
601-260 9.5 9.5 2.3/4" 4.1/4"
601-300 1/2" 1/2" 3" 4.3/4"
601-270 10 10 2.7/8" 4.1/2"
601-280 10.5 10.5 2.7/8" 4.1/2"
601-284 11 11 2.7/8" 4.1/2"
601-288 11.5 11.5 3" 4.3/4"
601-294 12 12 3" 4.3/4"

………………………………………………………………………………………………………………………………………………………..............................

Tel. (442) 642 59 10 y 642 59 11 www.dhisa.com.mx Correo. ventas@dhisa.com
