Page 178 - TCD Catalog 2017

TCD Parts Inc.
Liquid Testing

WAREWASH WATER LAUNDRY WATER QUALITY
QUALITY TEST KIT TEST KIT
The kits test Alkalinity, Hardness, Chlorine, The kits test pH (alkaline), pH (sour),
and Quaternary Ammonium Chloride. Alkalinity (suds), Alkalinity (rinse), Chlorine
Complete kit to set the desired chemical Cleach, Hardness, and Turbidity.
sanitizing scheduele for all dish machines.
Part # Description Part # Description
LM-1169 COMPLETE KIT LM-3095-LID COMPLETE KIT
Refill Part # Description Refill Part # Description
LM-2258-E PHENOLPHTHALEIN INDICATOR .5% 15ML LM-0230 TEST TUBE WITH CAP 5ML (QTY 3)
LM-2786-E TOTAL ALKALINITY INDICATOR 15 ML LM-0240 TEST TUBE ROUND BOTTOM
LM-4483-E HARDNESS REAGENT #5 15ML
LM-2197 NITRO GREEN pH OCTA-SLIDE 2 BAR
LM-4485-E HARDNESS REAGENT #6 15ML
LM-0342 PIPETTE GLASS DROP 20 ML
LM-4487WT-H HARDNESS REAGENT #7 60ML
LM-0369 PIPETTE ASSEMBLY WITH CAP
LM-7748WT-G SULFURIC ACID .12N 30ML (2 BOTTLES) LM-0392 PIPETTE PLAIN PLASTIC WITH CAP
TP-101 CHLORINE TEST STRIPS; 1 VIAL LM-0608 TEST TUBE WITH CAP GLASS 5-25 ML (QTY 2)
TP-103 QAC TEST STRIPS; 1 VIAL LM-2230-E METHYL ORANGE INDICATOR 15 ML

LM-4488 WATER HARDNESS TEST TUBE LM-2246-E PHENOLPHTHALEIN INDICATOR 1% 15 ML
LM-0715 TEST TUBE WITH CAPS 5-10-25 ML LM-2301-G NITRO GREEN INDICATOR 30 ML
LM-4483-E HARDNESS REAGENT #5 15 ML
LM-4485-E HARDNESS REAGENT #6 15 ML
GRADUATED CYLINDER
LM-4487PS-H HARDNESS #7 60 ML
LM-4488 WATER HARDNESS TEST TUBE
LM--6130PS-H HYDROCHLORIC ACID 1.0 N, 60 ML
LM-6323-H HYDROCHLORIC ACID 0.1N, 60 ML
LM-6432-H SOUR INDICATOR 60 ML
Part # Description LM-6434-H HYPOCHORITE INDICATOR 60 ML
10-70046 GRADUATED MEASURING CYLINDER 10 ML; PLASTIC LM-7941PS-H HYPOCHLORITE REAGENT C 60 ML
10-70048 GRADUATED MEASURING CYLINDER 50 ML; PLASTIC
LM-1011 OCTA-SLIDE 2 VIEWER
LM-0106 TEST TUBE 2.5-5-10 ML (QTY 2)

Test Range Applications
pH (alkaline) pH 10.0- 11.4 BREAK-SUDS-BLEACH SOLUTIONS
pH (sour) pH 1.5- 8.5 SOUR RINSE SOLUTIONS
Alkalinity (suds) 100 ppm/drop FREE/TOTAL ALKALINITY IN BREAK-SUDS-BLEACH SOLUTIONS
Alkalinity (rinse) 100 ppm/drop TOTAL ALKALINITY IN RINSES
Chlorine Bleach 0.5% /drop AVAILABLE CHLORINE IN BLEACH
Hardness 100 ppm/drop WATER SUPPLY
Turbidity Yes/ No (soil) PRESENSE OF SOIL IN SOLUTIONS

www.tcdparts.com 177
Customer Service (800) 823-8313
