Page 28 - TCD Catalog 2017

TCD Parts Inc.

Nova/Hydro Squeeze Tubes

SQUEEZE TUBE OPTIONS for:
Nova Warewash; Spite DM-400 & DM-700 Series

for detergent, rinse & sanitizer pumps

PART # PREFIX ID X OD W/ FITTINGS LENGTH OF TUBE MATERIAL OPTIONS
80- 024- NF- 100- HC

(HC) HI-CHEM™ - EPDM
(SIL) SILICONE

100’
50’
25’
6.25”
NF44 - 1/4” THREADED FITTINGS
NF48 - 1/4” & 1/8” THREADED FITTINGS
NF88 - 1/8” THREADED FITTINGS

024 - .080” ID X .240 OD RINSE
030 - .160” ID X .320” OD DETG./SANT.
80

SQUEEZE TUBE OPTIONS for:
Nova Drain Doser; Auto-Dose
material id od description part #
HI-CHEM™ (EPDM) .160” .320” 6 1/4” CUT TUBE W/ 1/4” THREADED FITTINGS 80-030NF44-6HC

SQUEEZE TUBE OPTIONS for:
Nova on Premise Laundry (OPL); LM 100 Orion & LM 200 Eclipse

PART # PREFIX ID X OD LENGTH OF TUBE MATERIAL OPTIONS
80- 050- 100- HC
(HC) HI-CHEM™ - EPDM
(HCXR) ULTRA-PREMIUM EPDM
(SA) SANTOPRENE
(SIL) SILICONE
(TP) NORPRENE® BI-WALL
(VT) VITON - SOLD ONLY BY FT. OR 12”

100’
50’
25’
12”

050- 1/4” ID X 1/2” OD

80
