Page 38 - TCD Catalog 2017
P. 38
TCD Parts Inc.
Beta Chemical Dispensing
DR2000 ALPINE
Drain DoserSystem Laundry Dosing
100 Series Pump 100 Series Pump
Includes installation kit with 25 ft. of 1/4” tubing, tube guide,
clamps & mounting hardware, batteries not included.
Description Part # Alpine is for domestic-style topload and frontload washers requiring
two or three chemicals. Stores eight formulas. It has the options
CHEMICAL DISPENSER 115 VAC BT-1202356
of manual triggering, remote triggering and automatic triggering
CHEMICAL DISPENSER, BATTERY (D-CELL) BT-1202354
applications. Installation kit included.
REPLACEMENT PARTS FOR THE Description Part #
100 SERIES PUMPS 2 PUMPS BT-1201039
3 PUMPS BT-1201038
REMOTE CONTROLLER BT-1201630
REPLACEMENT PARTS FOR THE
8 oz. SERIES PUMPS
H-3000E
Ref # Description Part #
2 TUBE FITTING NUT, 1/8” RINSE BT-017458
2 TUBE FITTING NUT, 1/4” DETERGENT/SANITIZER BT-043823
4 SEE TCD TUBING SECTION FOR SQUEEZE TUBE
REPLACEMENT OPTIONS Ref # Description Part #
5 TUBE INSERT, 1/8” RINSE BT-036982 1 SCREW, PHILLIPS 6-32 X 3/4 (QTY 4) BT-040992
5 TUBE INSERT, 1/4” DETERGENT BT-036969 2 PUMP HEAD FRONT BT-059967
5 TUBE INSERT, 1/4” SANITIZER BT-090331 3 SEE TCD TUBING SECTION FOR SQUEEZE TUBE
REPLACEMENT OPTIONS
6 ROLLER ASSEMBLY, HIGH FLOW FLEX TUBE .25” ID BT-096707
4 ROLLER ASSEMBLY YELLOW .710 OD BT-051190
8,9 MOTOR/GEARBOX 24 VDC BT-E451038
4 ROLLER ASSEMBLY GREEN .780 OD BT-051189
8,9 MOTOR/GEARBOX 6 VDC (DR-2000 ONLY) BT-057755
5 SCREW FLATHEAD 8-32 X 3/8 (QTY 2) BT-040985
11 BLANK PUMP PLATE (2 EACH) BT-051606
5 SCREW PHILLIPS FLATHEAD 8-21 X 3/4 (QTY 2) BT-040986
12 SOLENOID ASSEMBLY, PLASTIC BT-091934
6 PUMP HEAD BACK BT-038850
13 SOLENOID ASSEMBLY, METAL BT-099312
7 MOTOR 115 VAC 100 RPM USED W/ L4000E BT-018051
COMPLETE ASSEMBLED CARTRIDGE W/ ROLLER, BT-1206740
AND PINS, NO TUBES 7 MOTOR 230 VAC 100 RPM USED W/ L4000E BT-018053
