> Winching

Winches on all
Britpart
Winches Winches

DB12000iR
If you are serious about off-roading then a winch
is an essential piece of kit. They are indispensable
when getting yourself and others out of tricky
situations.
The Britpart Pulling Power range of powerful and
reliable electric winches all feature a planetary
gear system for fast line speed, free spooling,
power in & power out and low electric current.
Now with the larger winches you have a choice of
having the traditional steel cable fitted or Dyneema
rope.
A full range of winching equipment is also
available from Britpart - including; safety gear,
bumpers, chocks, hooks, shackles & ropes.
Together with the winches you’ll be able to
‘Get to where you want to go!’

Features

3.6Kw (4.8Hp) 3.6Kw (4.8Hp) 2.7Kw (3.6Hp) 1.0Kw (1.5Hp)
Motors
Heavy-duty series wound DC motor Heavy-duty series wound DC motor Permanent magnetic DC motor Permanent magnetic DC motor
Models available 12 volts & 24 volts 12 volts & 24 volts 12 volts 12 volts

Steel cable or Steel cable Steel cable Steel cable Steel cable
Dyneema rope or Dyneema rope or Dyneema rope
Weather & dustproof DB12000iR   
Rated at IP67
contactor controls for waterproofness & dustproofness
Planetary gear
system for fast line    
speed
Automatic load   
holding brake
   
Free spooling
   
Power in & power out
   
Low electric current
 
Hardened drum
Specifications
Rated line pull 5,443kgs 4,309kgs 2,722kgs 907kgs
- single line 12,000lbs 9,500lbs 6,000lbs 2,000lbs
Gear reduction ratio 294:1 212:1 210:1 153:1
3.6Kw 3.6Kw 2.7Kw 1.0Kw
Motor size
4.8Hp 4.8Hp 3.6Hp 1.5Hp
67 x 228mm 67 x 228mm 63 x 140mm 32 x 71mm
Drum size - D x L
2.64 x 9” 2.64 x 9” 2.5 x 5.51” 1.26 x 2.8”
9.53mm x 30.5m 9.53mm x 30.5m 7.94mm x 26m 4mm x 15.2m
Steel cable - size
0.38” x 100’ 0.38” x 100’ 0.31” x 85’ 0.16” x 50’
11mm x 28m 11mm x 28m
Dyneema rope - size N/A N/A
0.43” x 91.9’ 0.43” x 91.9’
Overall dimensions 548 x 167 x 299mm 548 x 167 x 299mm 438 x 158 x 185mm 320 x 105 x 111mm
- L x W x H 21.57 x 6.57 x 11.77” 21.57 x 6.57 x 11.77” 17.24 x 6.22 x 7.28” 12.6 x 4.13 x 4.35”
Steel cable 43.0kgs 43.0kgs 31.8kgs 6.6kgs
- net weight 94.8lbs 94.8lbs 70.0lbs 14.6lbs
Dyneema rope 33.0kgs 33.0kgs
- net weight 72.8lbs 72.8lbs N/A N/A
254 x 114.3mm 254 x 114.3mm 166 x 114.3mm 48 x 76mm
Mounting bolt pattern
10 x 4.5” 10 x 4.5” 6.54 x 4.5” 1.89 x 3.0”
