Splice Jacketing, Rejacketing and Cable Repair: 3M™ Splice Jacketing and Rejacketing Kits

3M™ Heat Shrinkable Splice Jacket Kits HSJ

Series

3M™ Heat Shrinkable Splice Jacket Kits HSJ Series are designed to jacket power cable splices
installed on jacketed power cable. The sleeves physically cover the cable neutral wires to
environmentally protect the cable at the splice location. Fabricated from medium wall cross-
linked polyolefin, the sleeves are flexible, highly split resistant and fast shrinking to provide
rapid installation. The sleeves come with a factory applied adhesive/sealant. Sleeves are
supplied in black only.

Voltage 15–35 kV
Number of
Conductors Single Conductor

Min. Cable Kits
Expanded Sleeve Max. Splice Max. Cable
Order No. UPC Sleeve Length Jacket Compatible With per
I.D. Diameter Jacket Opening
Diameter Case
HSJ-1 054007-09270 33.0” (838,2 mm) 2.50” (64 mm) 0.85” (22 mm) 1.90” (48,3 mm) 22.0” (559 mm) 15 kV: 3M™ Splice No 5411, 10
5411A and 5412
HSJ-2 054007-09271 40.0” (1016 mm) 3.00” (76,2 mm) 1.00” (25,4 mm) 2.60” (66,0 mm) 28.0” (711,2 mm) 15 kV: 3M™ Splice No. 5403, 10
5404, 5405, and 5406
25 kV: 3M™ Splice No. 5420,
5421, 5422, 5451, 5451A,
5452, and 5451R
35 kV: 3M™ Splice No. 5432
and 5461
HSJ-3 054007-09272 40.0” (1016 mm) 4.30” (109,2 mm) 1.50” (38,1 mm) 3.40” (86,4 mm) 28.0” (711,2 mm) 15 kV: 3M™ Splice No. 5407, 5
5408, and 5409
25 kV: 3M™ Splice No. 5423,
5424, 5425, and 5426
35 kV: 3M™ Splice No. 5433
