TIAARA TIAARA

TIA-73685N TIA-73687N TIA-73859SH
Concealed Thermostat with control unit for 4-Outlets and integrated Shut-off valve Concealed Thermostat with control unit for 5-Outlets and integrated Shut-off valve Tiaara Rainjoy Shower 600 x 350mm AISI 304 stainless steel in chrome finish with RGB LED lights remote control & without installation kit for false ceiling
• Chromotherapy (RGB): LED x 0.23W with 12V Power Supply (SMPS) Including Controller, connecting to AC 100-240V, 50-60Hz • 2-functions • Rain • 4 X Mist

TIA-73859BR
False ceiling installation kit for Tiaara rainjoy Shower 600 x 350mm consisting of 1 Bracket, 4 Anchors, 4 Stud bolts, 12 Hex nuts (Compatible with TIA-73859SH)

600 10 44

1/2"BSP

350
56

65 Min. 60 100
3/4" BSP Outlet (II) 3/4" BSP Outlet (III) Max. 85 37 105 3/4" BSP Outlet (II) 3/4" BSP Outlet (III) Min. 60
3/4"BSP Outlet (IV) Max. 85 38.5 105
II III III
3/4" BSP Outlet (I) I OFF IV 3/4"BSP Outlet (I) II I OFF IV V

3/4"BSP Hot Inlet 3/4"BSP Cold Inlet + 3/4"BSP Hot Inlet 3/4"BSP Cold Inlet + 38°
300 NRV 3/4"BSP Outlet (IV) 38° 280 308 NRV 3/4"BSP Outlet (V) 280

WALL FLANGE WALL FLANGE
PLUG PLUG
