(d) Determine the slope of your graph plotted in Part (c).
..........................................................................................................................................................
.........................................................................................................................................................
.........................................................................................................................................................
.........................................................................................................................................................
[2 marks]
(e) Compare the value obtained in Part (d) with the theoretical value, S = Δt/mRC, where C is
DO NOT WRITE IN THIS AREA
the specific heat capacity of water. Comment on your result.
..........................................................................................................................................................
..........................................................................................................................................................
..........................................................................................................................................................
..........................................................................................................................................................
[2 marks]
Total 15 marks
2. The circuit in Figure 2 has been set up with a cell of e.m.f, E, and internal resistance, r.
I E
r
DO NOT WRITE IN THIS AREA
A V
R
Figure 2. Circuit diagram
One equation that is relevant to the circuit is:
V = E - Ir
