Vector Lite A

Vector Lite is a simple versatile solution for displays

B
Larger than a Pop-up display without the layout of a
full scale modular stand, Vector Lite is a fantastically
adaptable display solution.
- Easy to assemble prefabricated panel kit system
made from lightweight aluminium
- One cleverly designed channel supports a variety
of media; foam board, PVC, or textile fabric
- Can be single or double-sided
- Create straight or curved display solutions
- Optional lighting and LCD Screen brackets are
also available to maximise the functionality of
your display
Vector Lite

Model Code (h) x (w) mm
On this page
A - 950mm panel VLF-H3-00 2000 x 950 mm
B - Slim silver foot LN155 N/A
On opposite page
C - 450mm panel VLF-H1-00 2000 x 450 mm
D - 1450mm panel VLF-H5-00 2000 x 1450 mm
E - Frame post VLP-1000 N/A
F - Joining hook VLF-03 N/A
G - Post Moulding VLP-01 N/A

HOW TO BUILD WITH VECTOR LITE
Modular Solutions

1 2 3 4

Push all of the frame If you are joining frames To join frames side-by- If you are just creating
Corner Cleats together and together to make a larger side, simply attach a a wall with no corners,
tighten using Allen keys. frame, then push the Joining Hook into the you will need to
Straight Joiners together grooved frame-edge and add feet in order to
and lock into place using slot the frames together. stabilise the display.
grub screws. These can be secured in
place using grub screws.
