Page 279 - 產品

3.防焰性強：
PVC浪板屬防焰建材，具有自熄與不自燃特性，已通過美國UL94 V-
0垂直燃燒試驗，與CNS7614防焰一級試驗。

4.保溫隔熱效果顯著：
PVC浪板的中間層為發泡材料，其導熱係數低，隔熱保溫性能達到
最佳效果。實際測試5mm厚度熱傳導只有0.228 W/m.k，但是一般烤
漆浪板實際測試是7.428 W/m.k，數值越高傳熱越快、保溫隔熱效果
愈差。

3. Strong flame resistance:
PVC wave board is a flame-proof building material with self-
extinguishing and non-self-igniting properties. It has passed the UL94 V-0
vertical burning test in the United States and the CNS7614 flameproof
first-class test.
4. The thermal insulation effect is remarkable:
The middle layer of PVC wave board is a foaming material, which has
low thermal conductivity and the best thermal insulation performance.
The actual test of 5mm thickness heat conduction is only 0.228 W / m.k,
but the actual test of the general paint wave board is 7.428 W / m.k, the
higher the value, the faster the heat transfer, the worse the thermal
insulation effect.
