Operating

5 [EQ HS]
HS characteristic
[Gain]: Input gain, the signal strength can be increased or decreased by 18 dB. Default setting: 0 dB. Press on the controller
to activate the fine adjustment. Double-clicking on the value accepts it as the default value.
[Freq]: Frequency adjustment in a range of 1.5 kHz…15 kHz (default setting: 6.3 Hz) is done using the hardware controller
on the device or the software controller on the display. Press on the controller to activate the fine adjustment. Double-
clicking on the value accepts it as the default value.
6 [Time]: Controller to adjust the runtime depending on a virtual room size in a range of 0 s…15 s. Default setting: 8 s. Press
on the controller to activate the fine adjustment. Double-clicking on the value accepts it as the default value.
Runtime settings for the various effect types:
n Reverb: Min. 0.8 s, max. 12 s, default setting 1.6 s
n Room: Min. 0.4 s, max. 8 s, default setting 0.8 s
n Plate: Min. 0.4 s, max. 6 s, default setting 0.6 s

digital mixer

42
