Page 371 - 2020-2021 Racecar Engineering Drag Racing Parts and Accessories Catalog
P. 371

2020 DRAG RACING






         Max Torque Street/Strip Camshafts
        High-performance camshafts are ideal for street/strip or bracket racing, with an exceptional balance of horsepower and torque over a broad RPM range.
                                            RPM     Duration @ .050"   Valve Lift    Sep.   Valve Lash    Valve
             Part No.       Application     Range      Int./Exh.  Int./Exh.  Angle  Int./Exh.  Lifters  Springs
        Small Block Chevy 265-400
            HRC110991-08    Hydraulic Cam  1700-5700  220°/220°  .470"/.470"  108°  .000"/.000"  HRC91111  HRC98214
            HRC112031-08    Hydraulic Cam  3000-6500  232°/232°  .480"/.480"  108°  .000"/.000"  HRC91111  HRC98214
            HRC112681-12    Hydraulic Cam  2800-6800  235°/237°  .488"/.488"  112°  .000"/.000"  HRC91111  HRC98214
            HRC112681-06    Hydraulic Cam  3000-6800  235°/237°  .488"/.488"  106°  .000"/.000"  HRC91111  HRC98214
            HRC111002-08     Solid Cam     3200-6200  244°/244°  .510"/.510"  108°  .022"/.022"  HRC91115  —
            HRC111153-06     Roller Cam    2500-6700  246°/250°  .582"/.580"  106°  .018"/.020"  HRC91117  HRC98441
        GM LS
            HRC197715-10  Hydraulic Roller Cam  2000-7400  226°/236°  .525"/.525"  110°  .000"/.000"  HRC91113  —
        Big Block Chevy 396-454
            HRC122521-15    Hydraulic Cam  1600-5600  221°/235°  .504"/.504"  115°  .000"/.000"  HRC91111  —
            HRC120255-12  Hydraulic Roller Cam  3000-6000  230°/236°  .585"/.610"  112°  .000"/.000"  —  HRC98636
            HRC120245-12  Hydraulic Roller Cam  1800-5400  225°/231°  .567"/.578"  112°  .000"/.000"  HRC91161  —
            HRC120325-10  Hydraulic Roller Cam  2000-5800  229°/235°  .589"/.600"  110°  .000"/.000"  HRC91161  —
            HRC120405-12  Hydraulic Roller Cam  2600-6400  235°/241°  .618"/.618"  112°  .000"/.000"  HRC91161  —
            HRC122312-10     Solid Cam     2800-6600  250°/256°  .595"/.607"  110°  .022"/.022"  HRC91115  —
            HRC121153-10     Roller Cam    2500-6700  248°/255°  .660"/.675"  110°  .020"/.020"  HRC91127  —

         Max Effort Racing Camshafts
        Computer designed for racing, then dyno and track tested.
                                            RPM     Duration @ .050"   Valve Lift    Sep.   Valve Lash    Valve
             Part No.       Application     Range     Int./Exh.  Int./Exh.  Angle  Int./Exh.  Lifters  Springs
        Small Block Chevy 265-400
           HRC114013-06S*   Roller Cam    3600-7600   251°/257°  .640"/.640"  106°  .022"/.022"  HRC91117  HRC98441
            HRC111163-06    Roller Cam    3800-7800   255°/261°  .600"/.620"  106°  .022"/.022"  HRC91117  HRC98441
            HRC111133-06    Roller Cam    4000-7800   257°/267°  .600"/.600"  106°  .022"/.022"  HRC91117  HRC98441
        Big Block Chevy 396-454
            HRC121123-10    Roller Cam    3500-7200   270°/278°  .702"/.702"  110°  .025"/.025"  HRC91127  —
            HRC121033-12    Roller Cam    5200-8200   285°/295°  .810"/.765"  112°  .022"/.022"  HRC91127  —
        *Small base circle and 4/7 swap camshaft.

         Performance Hydraulic Lifters                     ProMax Mechanical Roller Lifters
        Rockwell tested lifters offer precise oil control for high   HRC91198          NEW!
        performance and racing use. Sets of 16.            Designed for big block Chevy Mark IV and
          Part No.               Application               Gen. V/VI engines, ProMax mechanical roller lifters
          HRC91111             Chevrolet V8 265-454        feature “full-time” high-pressure oiling for increased
         HRC91112 †  Chevrolet V8 265-454, Anti-Pump Up, Increases RPM Capability  durability. Lightened, steel alloy bodies with a specially-enhanced finish
          HRC91116       Chevrolet V8 265-454, Direct Lube, Street/Strip
          HRC91211           Ford V8 221-460, All Exc. “FE”  are combined with heat treated stainless steel link bars and case hardened
        †Pre-load must be set at .002"-.004" to achieve performance levels.  8620 rollers. Lifters include a .300" taller body to fit early, late model and
                                                           aftermarket blocks. Set of 16.
         Performance Mechanical Lifters
        HRC91115                                           Maximum Effort Retro-Fit Hydraulic Roller Lifters
        Ground crown faces extend lifter life. Rockwell tested. Fit all   Popular retro-fit style lifters are CNC-machined and fitted with precision
        265-454 Chevrolet V8’s. Sets of 16.                internal check ball valving, preventing “pump up” while
                                                           extending the usable RPM range. Sold in sets of eight pairs.
         “The Original” Direct Lube                         Part No.          Application
         Extreme Duty Mechanical Lifters                    HRC91160        SB Chevy 265-400
                                                            HRC91161    BB Chevy 396-454 Mark IV/Gen. 5
        A precise EDM cut .021" hole in the face supplies oil to the   HRC91774  AMC/Chrysler V8
        cam face to increase durability and reduce lobe wear with higher
        valve spring pressures and aggressive lobe profiles. Sets of 16.   Sportmax Mechanical Roller Lifters
         Part No.          Application                     HRC91152
         HRC91718      American Motors V8 304-401          Engineered for the sportsman racer, small block Chevy
         HRC91118        Chevrolet V8 265-454
         HRC91718   Chrysler “A” 273-360; “B”/“RB” 383-440  mechanical roller lifers are manufactured in the USA using
         HRC91218     Ford V8 221-460, All Exc. “FE”       8620 heat-treated steel bodies, 9310 steel roller, and
                                                           maximum strength bearings. Direct lube pin oilers offer added durability.
                                                           Black oxide finished for corrosion protection. Sold in sets of 16.


        370
   366   367   368   369   370   371   372   373   374   375   376
