2020 DRAG RACING

Fasteners

Flush Head Self-Ejecting Allen Buttons Mounting Brackets For 1" And
1-3/8" Springs (.0625" Thick)
10-Pack 50-Pack
5/16"
.500" Long, Steel ALL19130 ALL19131 ALL19360
.550" Long, Steel ALL19132 ALL19133
7/16"
.500" Long, Steel ALL19136 ALL19137 ALL19384 ALL19380
.550" Long, Steel ALL19138 ALL19139

Winged Head Self-Ejecting Buttons ALL19394 ALL19390
10-Pack 50-Pack
5/16" Description 10-Pack 50-Pack
.400" Long, Steel ALL19040 ALL19042 Weld-on, Lightweight (For 1-3/8" Spring Only) ALL19360 ALL19362
.450" Long, Steel ALL19046 — Weld-on, Lightweight w/.375" Spring ALL19361 ALL19363
.500" Long, Steel ALL19050 ALL19052 Weld-on LH ALL19380 ALL19382
.550" Long, Steel ALL19056 ALL19058 Weld-on RH ALL19384 ALL19386
.650" Long, Steel ALL19060 ALL19062 Rivet-on LH ALL19390 ALL19392
7/16" Rivet-on RH ALL19394 ALL19396
.500" Long, Steel ALL19064 —
.650" Long, Steel ALL19068 —
Springs
Body Reinforcing Plates 10-Pack 50-Pack ALL19320
1-3/8" (.090" Wire Diameter)
Plates help protect fiberglass and aluminum .325" Reach ALL19320 ALL19322
panels from cracking when using 7/16" quick turn fasteners. Stainless steel .375" Reach ALL19330 ALL19332
.425" Reach
plates are precision stamped with a strengthening border, attach with 1/8" 1" (.080" Wire Diameter) ALL19336 ALL19338
rivets and measure 2" wide x 1" tall. .250" Reach ALL19300 ALL19302
Part No. Description .325" Reach ALL19310 ALL19312
ALL18985 10-Pack 3/4" (.062" Wire Diameter)
ALL18985-50 50-Pack .200" Reach ALL19296 ALL19298
Mounting Brackets For 1" Springs (.0625" Thick) Clamp-on Quick-Turn Fastener Brackets
These cool brackets let you to clamp NEW!
a quick-turn bracket to round tubing.
Allows a flush mount bracket behind a panel without
grinding your powder coat. For use with 1-3/8" quick-
ALL19364 ALL19340
turn springs, insert plates, or threaded nut inserts.
Description 10-Pack 50-Pack
Weld-on, Lightweight ALL19364 ALL19366 Black anodized.
Weld-on Lightweight w/.250" Spring ALL19365 ALL19367 Part No. Size
Weld-on ALL19340 ALL19342 ALL19430 1"
Weld-on w/ALL19300 Spring ALL19350 ALL19352 ALL19431 1-1/4"
ALL19432 1-3/8"
Quick-Turn Wrench ALL19433 1-1/2"
ALL19434 1-5/8"
ALL19400 ALL19435 1-3/4"
The Allstar quick-turn fastener wrench fits slo-head fasteners and reduces
the risk of body panel or fastener damage when using screwdrivers for Quick-Turn Fastener Insert Plates
loosening or tightening. Features a non-slip handle. Insert plate directly replaces the
quick-turn spring allowing panels
to be bolted together or used
as a blind nut on a panel with
limited access. Inserts have
1/4"-20 threads and are typically riveted to the backside of a panel or
bracket with 1/8" rivets.
Part No. Description
ALL19420 1", 2-Pack
ALL19420-10 1", 10-Pack
ALL19422 1-3/8", 2-Pack
ALL19422-10 1-3/8", 10-Pack
