2020 DRAG RACING

XP1000 16-Volt Battery and 12/14/16-Volt Battery Intellichargers
Battery Charger Combo Kits Compatible with 12-, 14-, and 16-volt
Spill-proof sealed 16-voltlead acid batteries, Intellicharger has a 25-amp
battery helps maximize electrical XSPXP1000CK1 maximum output, three charging modes,
system efficiency. Purchase bat- LED indicators with ammeter to monitor
tery separately, or complete with status, and a built-in cooling fan. It weighs
16-volt battery Intellicharger or 24 lbs. and includes heavy-duty 6' cables
High-Frequency Intellicharger. and clamps.
Max. Part No. Description
Part No. Description Amps CA Length Width Height Weight XSP1005 12/14/16-Volt Battery Intellicharger
Battery Only XSP1005E* 12/14/16-Volt Battery Intellicharger, 110/220 Input Option NEW!
*May be powered by 110- or 220-volts.
16-Volt
XSPXP1000 2400 675 10.24" 6.75" 7.20" 46.5 lbs.
Battery
16-Volt Battery Intellicharger
Part No. Description
Combo Kits XSP1004
XSPXP1000CK1 XP1000 16-Volt Battery And HF Intellicharger Combo Kit For use with 16-volt batteries, constant
XSPXP1000CK2 XP1000 16-Volt Battery And Intellicharger Combo Kit current/constant voltage charger has a
20-amp maximum output and two charg-
Battery Post Adapters ing modes. LED indicators with ammeter
Brass adapters allow use of conventional post-style termi- monitor status, and a built-in cooling fan
nals on XS Power batteries. Sold in pairs with fasteners. increases reliability. Charger weighs just 16 lbs. and includes heavy-duty 6'
cables and clamps.
Part No. Description
XSP551 I-Bar Side And Top Terminal Adapter
XSP580 Short Brass Post Adapters, M6 Voltage Step Down Module
XSP586 Tall Brass Post Adapters For 925/1200 Models, M6 XSP993
XSP587 6mm To 3/8” Stud Adapter, Zinc Plated Step down selected electrical compo-
nents when using a 16-volt battery. 50-amp maximum.

Platinum Twin-Shaft Rocker Arms Platinum Single-Shaft
Intake and exhaust rockers are joined in pairs on Rocker Arms
a shaft that is 22% larger and engineered for Affordable shaft-type platinum rockers for
extreme RPM. Maximum width bearings deliver canted valve engines such as Chevy and Ford.
greater rigidity, resistance to breakage, and Dowel pins under each mount prevent rocker
superior load carrying ability, eliminating the misalignment and rotation. Sold in sets of 16.
need for screw-in studs. Rocker arms bolt to existing Part No. Description Cylinder Head Ratio
7/16" stud mountings with supplied bolts. Easy to service YTRYT6603 BB Chevy 396-454 OE/Brodix/Dart/Edelbrock/World 1.7
Ford 351C,
in the field. Sold in sets of 16. YTRYT6321 351M-400, 429-460 OE/CJ/SCJ/Motorsport/Trick Flow/Wilburt 1.73
Part No. Description Cylinder Head Ratio
OEM/Bowtie/AFR/Dart/ Rocker Pedestal And Saddle Shim
YTRYT6008 SB Chevy 265-400 1.55/1.55
World/Brownfield
OEM/Bowtie/AFR/Dart/ YTRYT6241
YTRYT6009 SB Chevy 265-400 1.6/1.6
World/Brownfield Engineered for use with Platinum twin-
OEM/Bowtie/AFR/Dart/
YTRYT6341* SB Chevy 265-400 1.6/1.5 shaft rockers, shim is .100” thick and
World/Brownfield
YTRYT6620 SB Chevy 265-400 Dart Pro-1 1.5/1.5 may be used to obtain proper valve train
SB Ford Windsor Brodix/Dart/Edelbrock/
YTRYT6323 1.6 geometry. Sold each.
289-351W Motorsport/Trick Flow
* Rocker arms in this kit have an extra .070" pushrod offset on intake for repaired or wider
ports.
