Page 251 - 2018 Racecar Engineering Open Wheel Parts and Accessories Catalog

Extended Length Screw-In Swivel Feet Tire Tape LON52-50870
LON52-72890 Tape is 1/4" wide x 10' long.
<ZLK VU ZJHSL WHK HUK YVSS VɈ
levelers, replacement swivel feet
feature 1/2"-13 threads extended to
8" LON52-52-g for increased adjustment Toe-In Plates
capability. Sold in package of two.
LON52-79501
Rest plates against the tire
Replacement Pop-Out Feet on each side and use a tape
LON52-72896 measure. Two tape measures
included.
4" Pop-out swivel feet. 2-Pack
Deluxe HD Toe-In Plates
Aluminum Turn Plates
LON52-79800 LON52-79505
Thick, heavy duty toe plates provide
Check Ackermann and other steering increased accuracy, and include a higher
related settings with outstanding ac- kick-out on bottom, which holds the
curacy. Lightweight design reads to 1/2° plate against the wheel better. Magnets
HUK PZ MYLL ÅVH[PUN PU [^V KPYLJ[PVUZ MVY UV on one plate holds measuring tapes in place and
bind. Can be zeroed with the car in place. an incorporated pointer allows obtaining easy, accurate
Pair. Use with LON52-79750 spacers. measurements. Sold per pair.

Mini Chassis Height Checker LON52-78318
( ZOVY[LULK ZPTWSPÄLK ]LYZPVU 4PUP \UP[ JOLJRZ
chassis height quickly and accurately. Simply
QuickSet Digital Caster/Camber Gauge push unit under car, raise the tape with
For Large Wheels LON52-78298 the knob, pull it out and read the height.
,UNPULLYLK MVY YVHK YHJL HWWSPJH[PVUZ Ä[[LK Unit is accurate to 1/16" and has a range
with 17" to 22" cast aluminum wheels, new of 2"-8".
model QuickSet Caster/Camber gauge for Note: Unit does not measure height dynamically as you work, or if car is
large wheels includes special “feet” that on scales. It must be removed to read chassis height.
adapt to wheel bead and center the gauge. Digital
Acculevel gauge reads to .1". Unit folds up for easy Roller Stagger Gauge LON52-50846
storage. Sold complete with a foam-lined silver storage
case. Stagger gauge incorporates a
single roller to allow easier, more
accurate measurements. Manu-
Toe-In Bar factured from rigid, 3/8" thick T6
billet aluminum. The stagger gauge
LON52-79622 includes two scales, which allow it to be used on the car, or on the
One person can perform toe ground.
measurements more quickly and easily.
Similar to LON52-gacre #79620, but this new model requires no
scribe line and measures to the outside of the tire. Slide the rod Hydraulic Bump Stop Spring Rater
against the tire and measure toe to within 1/16". Toe-in bar is con- Specialized spring rater allows rat-
structed from billet aluminum and features small wheels, allowing ing bump stops, setting preload, testing
it to easily slide underneath the car. Suitable for use on wide track coil-overs or springs only. Spring rater is
cars including Corvettes, etc. manufactured from rigid billet aluminum,
features a digital display with both force
and travel readouts. Unloader attachment
Toe-In Gauge allows installing or removing very soft
LON52-79620 springs. Unit features a 3,500 Lb. capac-
When used with the LON52-79610 Tire Scribe ity in 1 Lb. increments. Optional wheel kit
(available separately) one person can accurately set toe-in. eases transport.
Part No. Description
Bump Stop Spring Rater,
Billet Aluminum Tire Scribe LON52-73501 3,500 Lb. Capacity
LON52-79610 LON52-73504 Optional Wheel Kit
Designed for use with LON52-79620 Toe-In LON52-73509 1" Shock Unload Collar
Gauge, Tire Scribe makes a true running line
on the face of the tire. Rigid, billet alumi-
num scribe is spring loaded for easy, one
person use.

250
