Brake Bleeder Bottle QRP66-700 Plastic Caps and Plugs
Bleed brakes with no mess. High grade hose offers QRP64-225
a better seal on the caliper bleeder valves and the Kit fi ts, -4 through -16 male caps and female plugs.
bottle has an extra nipple so the hose can be hooked
back into the bottle for draining. Bottle also includes a
lanyard so bottle can be suspended from a suspension MSD Box Quick Release Mount
part.
QRP50-442
Mount fastens to car with quick
fasteners allowing quick installa-
tion and removal.

SDK Disc Brake Kits
QTM offers a wide variety of high performance disc brake kits to the open wheel market that offer superior braking in an exceptionally light-
weight package. Each SDK brake kit includes aluminum alloy calipers, three-piece, standard blade brake rotors and necessary hardware.
Rigid calipers resist caliper fl ex under high line pressures, improving pedal feel, caliper performance and pad wear. Durable, hard coated
aluminum caliper pistons provide improved durability, resistance to corrosion and increased dimensional stability through the entire thermal
cycle. Rotors incorporate a proprietary friction surface that offers improved braking when compared to traditional iron, aluminum or titanium
rotors, while the three-piece design delivers up to 400°F reduced operating temperatures. Floating rotor design eliminates uneven pad wear
and warping, while dramatically improving pad life.
SDK-1 Sprint Car Dirt SDK-6 Rear Inboard Brake Kit
Front Brake Kit QTBSDK-1 QTBSDK-6
Part No. Description Caliper and Mounting bracket: Aluminum
Front Caliper And Rear Alloy for both pistons and caliper allow
QTB140-1602X
Outboard Caliper, RR for dimensional stability through thermal
QTB230-5402X Front Rotor cycle. Internal tolerances are maintained
QTB330-5003X Sprint Car Dirt Bracket at all temperatures (Unlike Stainless
QTB500-4003 Front Caliper Pads piston and aluminum caliper combina-
tions). QTM Hard-Coating of pistons
& bores resist corrosion, signifi cantly
improve wear. Knock Back springs to
reduce long pedal. Titanium heat shields.
Engineered to resist caliper fl ex at high line
pressures. Improves pedal feel and caliper performance. Typical op-
SDK-3 Sprint Car erating range 0-1500 PSI. Large M10x1.0 bleeders eliminate thread
Dirt Rear Brake Kit - stripping at exactly the worst possible time. Internal crossover
design allows for easy bleeding of system.
Outboard RR QTBSDK-3 Rotor: 10-1/2" x 9/16" Multi Piece Rotor. Stainless steel/iron al-
Part No. Description loy friction surfaces (they are magnetic). Aircraft quality Titanium
QTB140-1602X Front Caliper And Rear Outboard Caliper, RR “fi ngers” create airgap and pump air for cooling. The best stopping
QTB430-5106X Sprint Car Dirt, Outboard RR power available. Extremely high cold and hot coeffi cient of friction.
QTB500-4005 Pads For Rear Outboard Caliper Long life.
Rotor-Mounting Clamp: Aircraft quality billet aluminum clamp.
Super-strong clamp mounts rotor in double-shear. Titanium rotor
Individual mounting bolts. “Clock” on/off design allows rotor to be taken off
Brake Components QTB140-1602X the car WITHOUT removing clamp. Extra wide design for greater
stability.
Part No. Description Brake Pads: Sintered pad for extremely high coeffi cient of friction.
Calipers Long life.
QTB140-1602X Front Caliper And Rear Outboard Caliper, RR Part No. Description
Rotors Related Components
QTB230-5402X Front QTB230-5303X Inboard Rotor
QTB230-5300X Sprint Car Dirt Rear, Inboard For Use With QTB Clamp
Front Brackets
QTB330-5003X Sprint Car Dirt
Rear Brackets
QTB430-5106X Sprint Car Dirt, Outboard RR
QTB430-5107X Sprint Car Dirt, Outboard RR, Flange Rotor Mount
Pads
QTB500-4003 Front Caliper
QTB500-4005 Rear Outboard Caliper
QTB500-5001 Rear Inboard Caliper, QTB Sintered Pad
