Page 348 - 2018 Racecar Engineering Open Wheel Parts and Accessories Catalog

“The Goose” Gooseneck Hitch REE58079 Adjustable Hitch Bars
“The Goose” eliminates Designed for weight distributing hitches, bars may be
cutting the truck bed and used in the raised or dropped position.
may be used in conjunction Part No. Description Length Drop Rise
with a Reese fifth wheel hitch. REE3215 2" x 2" Hitch Bar 14" 6" 10-1/4"
Gooseneck style hitch features REE54970 2" x 2" Hitch Bar 12" 4"-6" 8-3/4"
a 25,000 pound gross trailer
weight and 6,250 pound pin
weight capacities. Unit uses Weight Carrying
the same base rails as standard fifth wheel hitches, and may be Draw Bars
quickly removed with four locking pins. Includes large, 2-5/16" diam-
eter heat treated ball. Requires rails and installation kit. Rugged, heavy duty steel 2" x 2" draw bars
have 1" diameter hitch ball holes.
Part No. Description
REE30035* Rails And Installation Kit, Required To Install REE58079 Trailer/Tongue
Part No. Length Drop Rise Capacity, Lbs.
* Will not fit Ford F-150 4-door SuperCrew, SuperCab or any other 5-1/2' bed.
REE40343 10-1/2" 2" 3/4" 6000/600
REE40326 9" 7-1/2" 6-1/4" 5000/500
Class III And IV REE21347 10" 8" 6-3/4" 5000/500
Receiver Hitches
Reese offers custom fit (“no drill”) Hitch Balls
and universal Class III and IV Hitches. Solid steel, chrome plated hitch balls are offered in a
Each hitch includes mounting hardware. Hitch draw bar and ball variety of sizes.
must be purchased separately. Please see the receiver hitch rating Part No. Ball Dia. Shank Dia. Length Capacity
guide below and call for specific applications. REE63908 2-5/16" 1" 2-1/8" 7,500 Lbs.
Tongue Weight (TW) REE63909 2" 1" 2-1/8" 7,500 Lbs.
Weight Class Gross Vehicle Weight (GVW) With Weight Distributing (WD)
Receiver Hitch Rating Guide
Class III 8,000 Lbs. 800 Lbs.
Class IV 12,000 Lbs. 1,200 Lbs. Receiver REE63223
Class V 14,000 Lbs. 1,700 Lbs. Hitch Accessories
Part No. Description
High Performance Trunnion Style Reducer Sleeve,
REE58102 Reduces 2-1/2" Titan Opening To 2"
Weight Distributing Hitch Hitch Lock,
Hitch includes a one-piece, cast REE63223 Class III Bent Pin Dead Bolt Lock, Includes (2) Keys
head and a raised hitch ball platform Pull Pin And Cotter Pin Set,
to reduce the need for raised hitch REE63240 5/8" Dia. Class III/IV Groove Style
balls. Also features easy to use REE118020 Plastic Truck End 7-Way Adapter
adjusting blocks, and a new square
adjusting washer which allows eight adjustments for extremely REE118021 Plastic Trailer End 7-Way Adapter
accurate weight distribution. It’s now possible to “fine tune” weight
distribution on even the trickiest of rigs. Replacement ball mount is T-Connectors
REE58167.
T-Connectors make quick work of wir-
Part No. Description Max Hitch Wt. Max GTW ing four-way flat plugs. Easily connect to
REE66021 † Weight-Distributing Hitch 800 Lbs. 10,000 Lbs. the vehicle’s wiring harness for a factory
REE66022 † Weight-Distributing Hitch 1,200 Lbs. 12,000 Lbs. appearance with no cutting, splicing or
† Hitch bar sold separately. taping. Call for specific applications.
Weight Distributing Snap-Up Bracket
REE21501 Brake Control, 1 To 2 Axle Trailer
Replacement bracket fits a variety of weight
distributing hitch systems including REE66021 REE83501
and REE66022. The BRAKEMAN brake controls are 100%
solid state. Units meet all NHTSA regula-
Dual Cam High-Performance Sway Control tions regarding tow vehicle/trailer stoplight
REE26002 activation. The perfect choice for today’s
towing vehicles.
Patented dual cam control prevents trailer NOTE: Brake Control Adapter Harnesses are available for popular applications.
sway before it begins, maintaining free and
easy vehicle and trailer interaction, while
eliminating the noise associated with friction
style units. System installs on the trailer and
requires no adjustment every time the trailer is
hooked up, unless hitch or tow vehicle loading are changed.
NOTE: Requires usage of a weight distributing hitch with integrated spring
bars such as REE66021 or REE66022.
347
