Page 174 - 2017 Racecar Engineering Circle Track Parts and Accessories Catalog

OUTER BEADLOCK RINGS MUDBUSTER BEADLOCK RING
Replacement outer rings are for Aero beadlock One-piece beadlock ring/mud cover is only 1-1/4
wheels. Offered in yellow or chrome plated steel, or pounds heavier than standard ring and is a direct fit on
gold anodized aluminum. any Aero beadlock wheel. An optional red plastic plug is
Part No. Description available for the center hole.
ARW54-500002 15" Yellow Outer Beadlock Ring, Steel Part No. Description
ARW54-500004 15" Chrome Outer Beadlock Ring, Steel ARW54-500002 ARW54-500000 Chrome Mudbuster Beadlock Ring ARW54-500000
ARW54-500001
Yellow Mudbuster Beadlock Ring
ARW54-500020 13" Chrome Outer Beadlock Ring, Steel ARW54-300004 Red Plastic Plug
BEADLOCK KIT
ARW54-500007 MUD COVERS ARW54-300001
Kit includes weld-on inner ring with mud cover FOR BEADLOCK WHEELS
tabs, yellow outer ring, bolt kit and mud cover Mud Covers attach to Aero beadlock wheels with
installation hardware. quarter turn fasteners, keeping mud out of the wheels.
Offered in durable ABS plastic or lightweight aluminum
Part No. Description
ARW54-500003 Replacement Bead Lock Bolt Kit construction, covers are sold complete with necessary
ARWP905504 Replacement Spring For Beadlock Ring fasteners, springs and rivets.
Part No. Description
ARW54-300001 White ABS Plastic Mud Cover
ARW54-300005 Chrome ABS Plastic Mud Cover
ARW54-300015BLK Black Aluminum Mud Cover
Replacement Components
ARW54-300002 Mud Cover Installation Kit
ARWP048337 Replacement Press Nut For Inner Beadlock Ring, Each
ARWP905504 Replacement Spring, Each
ARWP905509 Replacement Quick Fastener Button, Each
ARWP905510 Snap Ring For Quick Fastener Button, Each

STARTLITE HOSE AND FITTINGS
StartLite hose is 45% lighter than conventional high performance assemblies. Hose has a patented AQP elastomer inner tube and Nomex outer cover. Combine
with aluminum crimp-style fittings for substantial weight savings. Use for fuel, lube, coolant and air systems. Sizes -04 through -20. Crimp with Aeroquip
ET1000 Series crimp machine. May also be used with reusable fittings.
Hose Max. Oper. Min. Bend Weight Vacuum 3 Ft. 6 Ft. 10 Ft. 15 Ft. 20 Ft.
Dash Size I.D. O.D. Pressure Radius Per Ft. Service Length Length Length Length Length
-04 .22" .43" 500 2.00" .05 lbs. 20 AERFCU0403 AERFCU0406 AERFCU0410 AERFCU0415 AERFCU0420
-06 .34" .55" 500 2.50" .08 lbs. 20 AERFCU0603 AERFCU0606 AERFCU0610 AERFCU0615 AERFCU0620
-08 .44" .64" 500 3.50" .11 lbs. 20 AERFCU0803 AERFCU0806 AERFCU0810 AERFCU0815 AERFCU0820
-10 .56" .80" 500 4.00" .14 lbs. 20 AERFCU1003 AERFCU1006 AERFCU1010 AERFCU1015 AERFCU1020
-12 .69" .93" 350 4.50" .16 lbs. 20 AERFCU1203 AERFCU1206 AERFCU1210 AERFCU1215 AERFCU1220
-16 .88" 1.15" 350 5.50" .20 lbs. 20 – AERFCU1606 AERFCU1610 AERFCU1615 AERFCU1620
-20 1.13" 1.41" 350 5.50" .25 lbs. 20 AERFCU2003 – AERFCU2010 AERFCU2015 AERFCU2020
LIGHTWEIGHT CRIMP ALUMINUM FITTINGS FOR AQP RACING OR STARTLITE HOSE
Dash Size Crimp Swivel Dash Size Crimp Swivel Dash Size Crimp Swivel
Straight 45° Elbow 120° Elbow
-4 AERFBM4211 -6 AERFBM4222 -6 AERFBM4242
-6 AERFBM4212 -8 AERFBM4223 -8 AERFBM4243
-8 AERFBM4213 -10 AERFBM4224 -10 AERFBM4244
-10 AERFBM4214 -12 AERFBM4225 -12 AERFBM4245
-12 AERFBM4215 -16 AERFBM4226 -16 AERFBM4246
-16 AERFBM4216 90° Elbow 150° Elbow
-20 AERFBM4217 -6 AERFBM4232 -6 AERFBM4252
30° Elbow -8 AERFBM4233 -10 AERFBM4254
-6 AERFBM4272 -10 AERFBM4234 -12 AERFBM4255
-10 AERFBM4274 -12 AERFBM4235 180° Elbow
-12 AERFBM4275 -16 AERFBM4236 -8 AERFBM4263
-20 AERFBM4137* -10 AERFBM4264
* Signifies a non-swivel fitting. Lightweight crimp fittings must be assembled with -12 AERFBM4265
ET1000 Series crimp machine (AERET1000-PAP-013). Select AQP lightweight crimp fittings
for ultimate weight savings. Select AQP reusable fittings for field serviceability.

ET1000 SERIES CRIMP MACHINE AERET1000-PAP-013
Comes with air/hyd pump and tooling, including collet and spacer ring tooling package.
