SECOND GENERATION LATE MODEL TRANSMISSION
LATE MODEL TRANSMISSION The ultimate combination of
Lightweight aluminum cased performance, reliability and
Second Generation lightweight. High gear is direct
transmission weighs drive. Low gear and reverse are
only 31 lbs. and operated by an internal
possesses the lowest rotating hydraulic clutch which
weight and drag of any unit currently eliminates the regular
available, yet retains the strength and clutch. Measures 19" from bellhousing
durability of traditional Bert transmissions. The flange to end of output shaft.
elimination of the power-robbing counter shaft adds significantly to the Part No. Description
reduction in rotating mass. Transmission is offered in three versions; standard BER200 Aluminum Transmission, 48 lbs.
Bert length, Muncie length and ball spline model. Shifter must be purchased BER201 Magnesium Transmission, 36 lbs.
separately.
Part No. Description BALL SPLINE TRANSMISSION
BERSG1300 SG Transmission, Standard Bert, 19" Length Ball spline tail housing system
BERSG1400 SG Transmission, Muncie, 22" Length is an option on alumi-
BERSG1500 SG Transmission, Ball Spline Model num and magnesium
BERSG1310 Shifter For SG Transmission Bert transmissions. Eliminates
BERSG1311 Shifter For SG Transmission, Bloomquist Style hidden bind, while allowing up to
5" of driveshaft yoke travel.
SECOND GENERATION Part No. Description
LATE MODEL TRANSMISSION BER204 Aluminum Transmission With Ball Spline
INTERNAL REPLACEMENT PARTS BER205 Magnesium Transmission With Ball Spline
Refer to diagram on the previous page for identification. Shifter and Coupler are Sold Separately.
Note: Bert transmissions DO NOT use 90W gear oil. Fill with Bert Blue
Part No. Description Magic transmission oil (BER444427) to 1/2" below filler hole.
BERSG-1000-10-10 Carrier Sub Assembly
BERSG-1003 Input Shaft, For SG1300/SG1400/SG1500
BERSG-1006 Sun Gear Selector BALL SPLINE
BERSG-1009 Carrier, Low And Reverse TAILHOUSING 1 2 3
BERSG-1011 Carrier Support Convert conventional
BERSG-1012 Sun Gear Bert transmissions to 4 5 6
BERSG-1016 Thrust Ring, Sun Gear telescoping, ball spline 7 8b
BERSG-1017 Selector Fork design for reduced 21 9a 9
BERSG-1018 Servo Piston friction. Telescoping 18 13
BERSG-1019 Band Actuator Shaft design smooths rear
BERSG-1021 Thrust Washer suspension movement.
BERSG-1029 Reverse Gear Manolite treating increases 19 20 17 16
BERSG-1030 Band And Band Anchor hardness and prevents corrosion. 15b 15 14 10
BERSG-1030-K 2nd Generation Band All components for conversion are included. 11
12
BERSG-1031 Reverse Bearing Part No. Description
BERSG-1032 Bearing, Carrier Thrust Support BER003BS Ball Spline Tailhousing
BERSG-1035 Plunger BER3-BS-OK Ball Spline Overhaul Kit, Includes Rear Seal, Wear Ring
BERSG-1039 Front Cover Gasket (12) 1/2" dia. Ball Bearings and CV Grease
BERSG-1052 Input Shaft Seal BER3-BS-OK-N Ball Spline Overhaul Kit, Includes Rear Double Seal,
BERSG-1053 Input Shaft Bearing Wear Ring (12) 1/2" dia. Ball Bearings and CV Grease
BERSG-1068 Breather Part No. Description Part No. Description
BERSG-1076 3/8" Double Row Chain Replacement Components Replacement Components
BERSG-1077 Servo O-Ring, 3/32" BER3-01 Output Shaft Tube BER3-14 Stop Washer
BERSG-1078 Piston Return Spring BER3-03 Front Bearing BER3-15B Front Seal, 2005 & Up Units
O-Ring, Reverse Idler Shaft,
BERSG-1079 BER3-05 Tailhousing, Ball Spline BER3-15-KG Greasable Ball Seal
3/4" O.D. x 5/8" I.D. x 1/16" Dia.
BERSG-1081 O-Ring, 1/16" x 1.000" BER3-06 Rear Snap Ring BER3-16 Tailhousing Seal
BERSG-1101 Gear Selector BER3-07 Ball Bearing, 1/2", Each BER3-17 Roller Bearing
BERSG-1150 Shift Rod Shaft Seal BER3-08B Ball Retainer Ring BER3-18 Ball Spline Shaft
BERSG-1151 Solid 3/8" Male Rod End, Shifter BER3-09 Allen Cap Screw, 1/4"-28 x 2" BER3-19 Wear Ring
BERSG-1157 Set Screw BER3-09A Hi-Lock Washer BER3-20 Friction Bushing
BERSG-1301 Late Model Tail Casting BER3-13 Aluminum Yoke BER3-27 Double Seal Ball Spline Conv. Kit
BERSG-1302 Output Shaft, For SG1300 BER3-13-S Steel Yoke BER19C Steel Washer, .090"
BERSG-1304 Output Bushing, For SG1300/SG1400
BERSG-1350 Ball Bearing, Deep Groove
BERSG-1502 Output Shaft, Ball Spline
BERSG-1503 Tail Tube, Ball Spline
BERSG-1506 Tailhousing Seal, Ball Spline
BERSP-CO300-040-0750M Detent Spring
