SMALL BLOCK CHEVY OIL PANS OIL PUMPS AND OIL PUMP DRIVE SHAFTS
CLAIMER OIL PANS Milodon oil pumps provide a 20-30%
Specifically for IMCA and hobby stock increase in volume and pressure. Flow tested
cars, five quart (plus filter) oil pans appear for quality and performance.
stock but house full length windage trays for Pump drive shafts are machined from
effective oil control. 7-1/2" sump depth. 4130 chrome moly, centerless ground
to avoid stress risers and then heat
Part No. De scrip tion
MIL31501 1986-up SB Chevy Oil Pan, RH Dipstick treated. For use with high volume/high
MIL31502 1980-85 SB Chevy Oil Pan, RH Dipstick pressure oil pumps. Chevy pump drives
MIL31503 Pre-1980 SB Chevy Oil Pan, LH Dipstick use pinned steel collars instead of plastic.
Oil Pump Pick-up, When Using MIL18750 Application Oil Pump Pump Drive
MIL18307
or Melling MELM55HV Oil Pump SB Chevy 283-400, MIL18750* MIL23050
High Volume/High Pressure, 5/8" Inlet
STREET STOCK SB Chevy Z-28 283-400, Std. Volume/High Pressure MIL18756 MIL23050
OIL PANS SB Chevy LT-1 350-400, High Volume, 3/4" Inlet MIL18740* MIL23050
Oil pans are 7-1/2" deep with 6 quart SB Ford 260-302, 25% More Pressure & Volume MIL18800 MIL22500
(plus filter) capacities, right side kickouts SB Ford 351W – MIL22560
and full length, quick fastener-mounted * High volume pumps are 3/8” deeper than stock.
windage trays.
Part No. Description OIL PUMP STUD MIL17050
MIL31512 1980-85 SB Chevy Oil Pan, RH Dipstick Stud is centerless ground from 8740 steel with
MIL31513 Pre-1980 SB Chevy Oil Pan, LH Dipstick rolled and heat treated threads, ground washer,
Oil Pump Pick-up, When Using MIL18750
MIL18308 Or Melling MELM55HV Oil Pump and nut. Fits small block Chevy.
LATE MODEL OIL PAN SMALL BLOCK CHEVY MAIN CAPS
Ideal for dirt/asphalt late models or modifieds Rigid main caps, CNC-machined from
with non-stock crossmember locations. Highly high strength ductile material, increase
effective trap door system and quick release the bottom end strength of 2- or 4-bolt
windage tray assembly offer continuous oil control. main blocks. Sold complete with required hardware.
Seven quart pan is compatible with large diameter Block must be align honed for installation.
flywheels and has a 12" long, 7" deep sump. Part No. Description
Part No. De scrip tion MIL11150 SB Chevy, OEM 2-Bolt Main, Angled Bolts
MIL31504 SB Chevy Late Model Oil Pan MIL11180 SB Chevy 400, 2- Or 4-Bolt Main, Angled Bolts
Oil Pump Pick-up,
MIL18305
When Using MIL18770 Or Melling MELM99HVS Oil Pump SB CHEVY
Oil Pump Pick-up,
MIL18306 LIFTER VALLEY SCREEN KIT MIL23150
When Using MIL18750 Or Melling MELM55HV Oil Pump
Stainless steel oil screens cover
LATE MODEL PRO COMPETITION OIL PANS drain back holes in the lifter valley,
Engineered for applications that preventing broken valve train debris
don't use a stock crossmember, pan from causing serious bottom end
includes a trap door system, full damage. Epoxy adhesive included.
length kickout and windage tray for
exceptional oil control. Compatible
with stock, large diameter flywheels. REINFORCED STEEL
Includes 1/2" NPT bung for a oil tem-
perature sender. Offered with sealed, dirt proof, screw-in style dipstick. Pan TIMING COV ER MIL65555
has a 7" deep x 12" length sump and a capacity of 7 qts., plus filter. Gold iridited small block Chevy steel timing cover has a
Part No. Description re in forced cam thrust area to prevent cam “walk.”
MIL31515 Pre-1980 SB Chevy Oil Pan, LH Without Dipstick
MIL31516 1980-85 SB Chevy/Dart SHP Oil Pan, RH With Dipstick
Oil Pump Pick-up,
MIL18305
When Using MIL18770 Or Melling MELM99HVS Oil Pump SMALL BLOCK CHEVY FASTENER KITS
Oil Pump Pick-up,
MIL18306
When Using MIL18750 Or Melling MELM55HV Oil Pump Milodon offers a variety of popular fasteners for small block Chevy.
Part No. Description
WINDAGE TRAYS MIL81300 Oil Pan Stud Kit
Windage trays provide maximum protection Engine Fastener Kit, Includes
against oil splashback. Louvered and Cylinder Head Bolts, Carb
“Diamond Stripper” screen type wind- And Valve Cover Studs, Intake,
age trays are available. Each requires a MIL83000 Timing Cover, Water Pump,
windage tray installation kit. Oil Pan, Header, Water Neck,
Part No. Description Distributor, Fuel Pump
And Balancer Bolts
MIL32100 SB Chevy 350 Louvered Windage Tray, LH Dipstick Harmonic Balancer Bolt,
MIL32101 SB Chevy 400 Louvered Windage Tray, LH Dipstick MIL84530 3/4" Hex Head
SB Chevy 350-400
MIL32250 MIL85000 Oil Pan Bolt Kit MIL83000
“Diamond Stripper” Windage Tray, RH or LH Dipstick MIL85400 Intake Manifold Bolt Kit
MIL81150 SB Chevy Windage Tray Installation Kit
