Page 342 - 2018 Racecar Engineering Engine Parts and Accessories Catalog

GASKETS

Chevrolet Small Block 283-400 5.7L LT1-LT4 (1993-97) (Cont.)

Head Gaskets (Cont.)
Gasket Bore & Cometic Fel-Pro / MLS GM SCE SCE SCE
Application Thickness MLS Fel-Pro OEM Mr. Gasket Performance Pro Copper Titan Spartan MLS
Iron/Alum. Blocks And Heads,
With Steam Holes 4.200" .062" — — — — — — SCES11206
Iron/Alum. Blocks And Heads, 4.200" .075" CAGC5249-075 — — — — — —
With Steam Holes
Iron/Alum. Blocks And Heads, 4.200" .080" CAGC5249-080 — — — — — —
With Steam Holes
Iron/Alum. Blocks And Heads,
With Steam Holes 4.200" .060" CAGC5403-066 — — — — — —
Iron/Alum. Blocks And Heads, 4.220" .040" CAGC5551-040 — — — — — —
With Steam Holes
Iron/Alum. Blocks And Heads, 4.270" .040" CAGC5215-040 — — — — — —
With Steam Holes
Iron/Alum. Blocks And Heads, 4.200" .032" — — — SCEP11205* — —
With o Steam Holes
Brodix Alum. Heads (Except BD2000) 4.200" .040" CAGC5403-040 — — — — — —
Brodix BD2000 Alum. Heads 4.200" .040" CAGC5408-040 — — — — — —
Brodix Alum. Heads (Except BD2000) 4.200" .051" CAGC5403-051 — — — — — —
MLS, Iron/Alum. Blocks, 4.200" .061" — FEL1144-061 — — — — —
Iron/alum. Heads
Iron Blocks, Alum. Heads Only 4.250" .051" — FEL1036 — — — — —
Embossed Steel, All 1955-91 — .018" — — MRG1130G — — — —
(Except 305/400)
MLS , Iron/Alum. Blocks, 4.230" .041" — FEL26478-041 — — — — —
Iron/Alum Heads With Steam Holes
MLS ROX Race Engine 4.280" .041" — FEL26476-041 — — — — —
4.500 Bore Centers
MLS ROX Race Engine
4.500 Bore Centers 4.280" .052" — FEL26476-052 — — — — —
MLS ROX Race Engine
4.500 Bore Centers 4.310" .041" — FEL26477-041 — — — — —
# Mr. Gasket MLS Multi-layer stainless with premier polymer coating * 400 gaskets listed above do not have steam holes between cylinders.
** Available in bulk 10-pieces, add "B" at end of part number to signify bulk. *** Requires receiver groove machined in head. **** Fel-Pro OEM

SCE Copper Head Gaskets Cometic MLS Head Gaskets Fel Pro Composite Head Gaskets
Intake Gaskets
Port Fel Pro / SCE
Application Dimensions Description Fel Pro OEM Mr Gasket Edelbrock Cometic Accuseal E Brodix
Brodix Aluminum Heads 4.200" .066" — — — CAGC5403-066 — —
Iron/Alum. Blocks And Heads, 4.200" .066" — — — CAGC5249-066 — —
W/Steam Holes.
Stock w/Exh. Crossover 1.23" x 1.99" .080" Thick FEL1204 ** — — — — —
E-Tek Heads 1.08" x 2.11" .120" Thick — — EDE7235 — — —
Stock Or Small Race Port 1.28" x 2.09" .060" Thick FEL1205 ** — — — — —
MRG101B,
Stock Port 1.25" x 2.00" .062" Thick — — — — —
MRG5820@
SBC w/Bowtie Cyl. Heads 1.14 "x 2.20" .060" — — EDE7206 — — —
Stock Port and Bolt Location 1.20" x 1.87" .060" — MRG100 — — — —
Stock Port and Bolt Location 1.25" x 2.00" .120" — MRG101 — — — —
350 5.7L Vortec, 1997-2000 1.31" x 2.37" .120" — MRG136G — — — —
350 5.7L LT1, 1992 1.24" x 2.06" .060" — MRG135G — — — —
350 5.7L 1985-88,
Upper and Lower Set 1.75" Dia. .125" — MRG146 — — — —
** Available in bulk 10-pieces, add “B” at end of part number to signify bulk. @ Mr. Gasket Ultra Seal

2018 ENGINE BUILDER CATALOG 341
