Page 441 - 2018 Racecar Engineering Engine Parts and Accessories Catalog

FASTENERS

Chevy Big Block 396-454 (Cont.)

Part No. Description PSI Rated At
Connecting Rod Bolts
ARP
ARP135-6001 Hi-Perf. 8740 For 454-502, 7/16" Bolts 190,000
ARP135-6002 Hi-Perf. 8740 For 396-427, 3/8" Bolts 190,000
ARP135-6021 Hi-Perf. 8740 For 454-502, 7/16" 2-Pack 190,000
ARP135-6022 Hi-Perf. 8740 For 396-427, 3/8" 2-Pack 190,000
ARP135-6401 Hi-Perf. Wave 8740 For 454-502, 7/16" Bolts 190,000
ARP135-6402 Hi-Perf. Wave 8740 For 396-427, 3/8" Bolts 190,000
ARP235-6401 Pro Wave 2000 For 454-502, 7/16" Bolts 220,000
ARP235-6402 Pro Wave ARP2000, 396-402-427-454, 3/8" Rod Bolts (16) 190,000
ARP235-6403 Pro Wave ARP2000, 409, 7/16" Rod Bolts (16) 220,000
ARP135-6001
Manley
MAN42249-4 Replacement Rod Bolts, 7/16" ARP2000 Cap Screws, 1.600" UHL (4) 190,000
HP Wave-Loc Series rod bolts With additional knurl are rated at 190,000 PSI. Pro Series Wave-Loc bolts are rated 220,000 PSI of
tensile strength.
Part No. Description
Head Bolts ALL87002
Allstar Performance
ALL87002 Stock OEM Style Head Bolt Set, Complete Set (2) Heads
ARP
ARP135-3601 Hi-Perf. 6-Pt., Cast Iron OEM
ARP135-3602 Hi-Perf. 6-Pt., 409 Cast Iron OEM
ARP135-3603 Hi-Perf. 6-Pt., Late Bowtie Alum., World, Merlin, Iron Dart
ARP135-3605 Hi-Perf. 6-Pt., Dart Alum., Exh. Side Bolts Only, 8-Pcs.
ARP135-3606 Hi-Perf. 6-Pt., Brodix Alum. -2, -4, Canfield
ARP135-3607 Hi-Perf. 6-Pt., Mark V With World Merlin, Late Bowtie, Dart Alum.
ARP135-3609 Hi-Perf, 6-Pt., Mark IV Or V Block With Brodix Alum. Heads
ARP135-3610 Hi-Perf. 6-Pt., Edelbrock EDE85519 Cyl. Heads
ARP135-3611 Hi-Perf. 6-Pt., Mark IV Or V Block With 77-Series Edelbrock Heads
ARP135-3701 Hi-Perf. 12-Pt., Cast Iron OEM
ARP135-3702 Hi-Perf. 12 Pt., Brodix Alum. -2, -4, Canfield
ARP135-3703 Hi-Perf. 12-Pt., Late Bowtie Alum., World, Merlin, Iron Dart
ARP135-3704 Hi Perf. 12-Pt., Cast Iron Block With Stainless 300 Outer Row
ARP135-3705 Hi-Perf. 12-Pt., Dart Alum. Exh. Side Bolts Only, 8-Pcs.
ARP135-3706 Hi-Perf, 12-Pt., Mark V With 502 Heads
ARP135-3707 Hi-Perf. 12-Pt., Mark V With World Merlin, Late Bow., Dart
ARP135-3710 Hi-Perf. 12-Pt., Mark IV Or V Block With 60 Series Edelbrock Heads
ARP135-3712 Pro-Series 12-Pt., Mark IV Or V Block With 315/335/357 Series AFR Heads
ARP235-3701 Pro Series 12-Pt., Cast Iron OEM
ARP235-3702 Pro Series 12-Pt., Brodix -2, -4, Canfield
ARP135-3601
ARP235-3703 Pro Series 12-Pt., Late Bowtie Alum., World, Merlin, Iron Dart
ARP435-3601 Stainless 300, 6-Pt., Cast Iron OEM Heads
ARP435-3701 Stainless 300, 12-Pt., Cast Iron OEM Heads
Edelbrock
EDE8551 Use With EDE6040, EDE6042, EDE6045, EDE6047, EDE6049, EDE6055
Head Bolt Kit For Victor Heads EDE77409, EDE77419, EDE77429, EDE77469, EDE77479,
EDE8554
EDE77489, Will Not Work In Stock Heads
EDE8581 Bolt Kit For EDE60809 And EDE60819 409 Performance RPM Cylinder Heads
EDE8551
Manley
MAN42170 Superior 170,000 PSI, OEM Big Block Chevy (1 Head)
MAN42192 Superior 170,000 PSI, Brodix Heads (1 Head)
MAN42322 Superior 170,000 PSI, Bowtie, Dart Alum., Merlin (1 Head)
Mr. Gasket
MRG941G Grade 8, Longer Than OEM, Use With Washers, 16-Pcs.
Head Studs
ARP
ARP135-4001 Iron/Alum. OEM Heads, Early Bowtie, Hex Nuts
ARP135-4002 348, 409 Head Stud Kit - Hex
ARP135-4207 12-Pt. Nuts, Merlin Alum. Block With Merlin, Jenkins Or Dart Heads
ARP135-4208 12-Pt. Nuts, Merlin Alum. Block With Merlin II/III Alum. Or Iron Heads
ARP135-4301 12-Pt. Nuts, Brodix Alum. Block With Brodix PB1200 Heads, Sonny's Heads
ARP135-4302 Brodix, Fits BB1, EFI, 2, 2T, 2X, 2 Extra, 3.4. 4 Extra. 5 Heads, With Brodix Alum. Block
ARP135-4303 Brodix, With Dart Pro 1 Or 360 Heads, With Brodix Alum. Block, 12-Pt.
ARP135-4304 Brodix, With Big Duke/Big Chief Heads, With Brodix Alum. Block, 12-Pt.
MAN42170
ARP235-4016 Merlin, World, Hex Nuts
