Page 464 - 2018 Racecar Engineering Engine Parts and Accessories Catalog

FASTENERS

Ford Big Block 429-460 & “FE” 390-428 (Cont.)

Part No. Description
Connecting Rod Bolts
ARP
ARP155-6001 Hi-Perf. 8740, 428 CJ, Replacement For 13, 32" Bolt ARP155-6001
ARP155-6002 Hi-Perf. 8740, “FE” 390-428, Except CJ
ARP155-6003 Hi-Perf. 8740, 429-460, 351W With Square Head
ARP150-6404 Hi-Perf. Wave 8740, Boss 429-460, Oval Head
ARP255-6402 Pro Wave ARP2000, “FE” 390-428
Head Bolts
ARP
ARP155-3601 “FE” 390-428 Hi-Perf. Series, Hex Bolts, Edelbrock EDE8557
ARP155-3603 "FE" 390-428 Hi-Perf. Hex Bolts With Blue Thunder Heads
ARP155-3604 429-460 Hi-Perf. Hex Bolts With Edelbrock RPM Heads
ARP255-3701 460 Pro Series 12-Pt. Bolts
ARP155-3601
Edelbrock
EDE8557 “FE” 390-428 With EDE6006 Or EDE6007 Edelbrock
Head Studs
ARP
ARP155-4001 “FE” 390-428, Hex Nuts
ARP155-4003 429-460 And 429CJ SVO Alum., Hex Nuts
ARP155-4201 “FE” 390-428, 12-Pt. Nuts
ARP155-4203 429-460 And 429CJ SVO Alum., 12-Pt. Nuts ARP155-4001
ARP155-4204 “FE” 390-428 Hi-Perf. 12-Pt. Pro-Series
ARP255-4305 460 with Trick Flow Pro Stock Heads, 12-Pt. Pro-Series
ARP255-4301 460 with Blue Thunder Heads, 12-Pt. Nuts
ARP255-4304 460 SVO Alum., 12-Pt. Nuts
All studs above feature 190,000 PSI of tensile strength.
Cam Bolts
ARP
ARP155-1001 Hi-Perf. 429-460, 12-Pt. 3, 8"-16 x 1.580" UHL (3)
ARP155-1002 Hi-Perf. “FE” 390-428, 12-Pt. 7, 16"-14 x 1.750" UHL (1)
ARP255-1002 Pro-Series, “FE” 390-428, 12-Pt. 7, 16"-14 x 1.750" UHL (1)
ARP255-1001 Pro-Series, 429-460, 12-Pt. 3, 8"-16 x 1.580" UHL (3)
Intake Manifold Fasteners
ARP
429, 460
ARP155-2005 Hex Head Bolt Kit, Black Oxide
ARP455-2001 Hex Head Bolt Kit, 300 Stainless
ARP455-2101 12-Pt. Bolt Kit, 300 Stainless
360-390-406-427-428 “FE”
ARP155-2002 Hex Head Bolt Kit, Black Oxide
ARP155-2102 12-Pt. Head Bolt Kit, Black Oxide
ARP455-2002 Hex Head Bolt Kit, 300 Stainless
ARP455-2102 12-Pt. Bolt Kit, 300 Stainless
Edelbrock
429-460
EDE8507 Fits Edelbrock 7105 Manifold ONLY
EDE8569 426, 460, 12-Pt Bolt Kit, Cadmium Finish
Rocker Arm Studs: See Pages 471, 472

2018 ENGINE BUILDER CATALOG 463
