Page 628 - 2019-2020 Racecar Engineering Circle Track Parts and Accessories Catalog

Aluminum And Magnesium (NQCVKPI *[FTCWNKE 4GNGCUG $GCTKPIU
Bellhousings 4XDUWHU 0DVWHU¶V IUHH ÀRDWLQJ K\GUDXOLF
Aluminum and magnesium bellhousings release bearing requires no machining
are offered in reverse mount, OEM-diameter and eliminates the slave cylinder and
DQG FOXWFKOHVV FRQ¿JXUDWLRQV 5HYHUVH PRXQW fork for bind-free operation. A positive
starter bellhousing has been thoroughly rede- return spring keeps the bearing off
signed using FEA Solid Works modeling and is the diaphragm. For use with Muncie or
80% stiffer than the original QTR110100, but is 3/4 lb. lighter. Borg-Warner T-10 input shaft with a bearing collar diameter of
1.375" and a master cylinder with a 3/4" bore. External bleeder
Part No. Description
QTR110100R Chevy Aluminum, Reverse Mount Starter, 10 lbs. and shims are included and bearing will work with either right- or
Chevy Aluminum, 153T, Block Mount Starter, left-hand bellhousing applications. Can be used with Quarter
QTR110104 Master or Tilton multi-disc racing clutches.
OEM Diameter, 10.0 lbs.
Description
Part No.
QTR110150R Chevy Magnesium, Reverse Mount Starter, Optimum-V QTR710100 Complete Bearing For 7-1/4" Clutches
QTR110300R Ford Aluminum, Reverse Mount Starter, 11.3 lbs. QTR710200 Complete Bearing For 4-1/2" And 5-1/2" Clutches
QTR110302 Ford Aluminum, 157T, OEM Diameter, No Mounts Replacement Components
QTR110200R Chrysler Aluminum, Reverse Mount Starter, 5.5"/7.25" Clutches QTR710101 Seal Kit For QTR710100 And QTR710200
QTR710102 Shim Kit For QTR710100 And QTR710200
QTR710103 Bearing Sleeve For 7-1/4" Clutches
7NVTC &WV[ 5VCTVGTU QTR710104 Bearing Sleeve For 5-1/2" Clutches
Starters pack plenty of punch (1.4 Kw) QTR710105 Remote Bleeder Kit
for all performance applications. Full ball
bearing construction and heavy-duty 6TK .KVG *[FTCWNKE 4GNGCUG $GCTKPIU
solenoids are not affected by normal under-
hood operating temperatures. Current draw is The Tri-Lite self-adjusting release
approximately 210 amps at rated load. bearing mounts in Quarter Master
factory-machined bellhousings.
Part No. Description
QTR114267B Reverse Mount/Reverse Rotation, Chevy/Ford Clutchless Bellhousing, 91T Weighs less than 1-1/2 lbs. with the
QTR114170 Reverse Mount/Standard Rotation, Bert/Brinn Bellhousing, 65T inlet and bleeder lines attached. The
QTR114180 Reverse Mount/Reverse Rotation, Clutchless Bellhousing, Old Style main body is the same for all part num-
QTR114260 Reverse Mount/Reverse Rotation, Quarter Master Bellhousing With Clutch bers, with varying piston lengths to accom-
QTR114270C Block Mount/Standard Rotation, Chevy LGC Block Mount, 105T modate the range of set-up heights in the
QTR114280 Block Mount/Standard Rotation, Chevy 153T/168T Flywheel/Flexplate 4XDUWHU 0DVWHU FOXWFK DQG À\ZKHHO OLQH 1R EXVKLQJV RU VKLPV
QTR114300 Block Mount/Standard Rotation, Ford 157T Flywheel/Flexplate are needed for installation. For instance, the Tri-Lite 730185
QTR114626 Reverse Mount/Reverse Rotation, LGC Bellhousing, 2.0 kW is recommended for the Pro-Series 5.5" 3-disc button clutch
Replacement Components assembly. .100" to .250" air gap (free play) is recommended for
QTR114030 Pinion Retainer Circlip, All Exc. QTR114170 new clutches.
QTR114045 Pinion Return Spring, Reverse Mount Starter
QTR114261 Adapter Mount For QTR114260 Part No. Description
QTR114292 Drive Assembly With Pinion Gear, Reverse Mount 91T Only QTR730185 Chevy 3-Disc Except On QTR509111 And 509112 Flywheels
QTR114940 Starter Shim Kit QTR730225 Chevy 2-Disc Except On QTR509111 And 509112 Flywheels
QTR730101 Seal Kit For Tri-Lite Bearings
QTR105030 Replacement Bearing Only
Pilot Bushings QTR710015 Replacement Fitting, -2 To -3AN
QTR730096 Replacement Bearing Base, .250" Shortened
Part No. Description
QTR110011 Chevy
Ford With Jerico, T-101, And T-10,
QTR110012 5VTGGV 5VQEM *[FTCWNKE 4GNGCUG $GCTKPI
Or Muncie Transmission
QTR110013 Chevy Extended Length (For Use With Motor Plate) QTR721100
Engineered for original equip-
Bellhousing Ball Stud ment-type 10.5" clutch diaphragms.
Redesigned bearing has increased
Designed for Chevys using a hydraulic release pressure capacity for compatibil-
bearing and mechanical linkage. ity with modern clutch systems.
Part No. Description Use with Saginaw, Muncie, T-10, and Jerico transmissions.
QTR110005 Hydraulic Release Bearing And Mechanical Linkage For Chevy
QTR110008 Hydraulic Release Bearing And Floating Bearing for Ford Note: Thick flywheels prohibit proper bearing engagement which may dam-
QTR110017 Aluminum Ball Stud, Race Bearing Only, Reverse Mount age components. Quartermaster flywheel QTR501100 will provide the extra
clearance.
Part No. Description
QTR710108 QTR106033 Replacement Bearing Only
/GEJCPKECN 4GNGCUG $GCTKPIU QTR710016 11" Remote Bleeder Line
QTR720102
Shim Kit
#PF $GCTKPI 4GVCKPGTU QTR721101 Seal Kit For QTR721100
QTR730012 Inlet Line
Part No. Description
QTR209130 Chevy Bearing, 7.25" Dia., 2-Disc
QTR309130 Chevy Bearing, 7.25" Dia., 3-Disc
QTR710108 Bearing Retainer, T-10, T-101
Note: Bearing retainers have a .800" seat height; shimming transmission
bolts to keep bearing parallel with transmission is unnecessary.
624 2019-20 CIRCLE TRACK PARTS AND ACCESSORIES
