REAR ENDS AND AXLES

Ring And Pinion Installation Kits
$OOVWDU ULQJ DQG SLQLRQ LQVWDOODWLRQ NLWV DUH DYDLODEOH ZLWK RU ZLWKRXW EHDULQJV .LWV FRQWDLQ DOO WKH KDUG WR ¿QG LQGLYLGXDO SDUWV IRU D
TXLFN WURXEOH IUHH LQVWDOODWLRQ SHIM KITS INCLUDE:*
BEARING KITS INCLUDE:* • Pinion Seal
• Pinion And Side (Carrier) Bearings • Pinion Depth Shims
• Pinion Seal • Adjustable Side (Carrier) Shims,
• Pinion Depth Shims Two (If Applicable)
• Adjustable Side (Carrier) Shims • Crush Sleeve Or Solid Spacer
• Crush Sleeve Or Solid Spacer • Pinion Nut
• Pinion Nut • One Ounce Tube Of Silicone Or Gasket
• One Ounce Tube Of Silicone Or Gasket • Gear Marking Compound
• Gear Marking Compound • Ring Gear Bolts
• Ring Gear Bolts
* Kit components shown for reference only, specific components will vary depending on application.
Bearing Kit Shim Kit Carrier Type Application
General Motors
ALL68515 ALL68615 10-Bolt 7.5", Passenger And Light Truck S-10 1982-1998
— ALL68616 10-Bolt 7.5", Passenger, Except Monza 1977-1981
— ALL68622 10-Bolt 8.2", Chevy Passenger And G-10 Van, 30-Spline Pinion
ALL68521 ALL68621 10-Bolt 8.5", 30-Spline Pinion Passenger And Light Truck
ALL68518 ALL68618 12-Bolt 8.875", Chevy And GMC Truck And Blazer, 1.438" Pinion
ALL68519 ALL68619 12-Bolt 8.875", Chevy Hi-Performance Passenger Axle, 1.625" Pinion
Chrysler
ALL68532 ALL68631 8-3/4" 489 Casting With 2.000" I.D. Carrier Bearings (Large #9 On Side Of Casting)
ALL68531 ALL68631 8-3/4" 489 Casting With 1.796" I.D. Carrier Bearings (Large #9 On Side Of Casting)
ALL68537 ALL68637 8-3/4" 742 Casting With 1.796" I.D. Carrier Bearings (Large #2 On Side Of Casting)
Ford Motor Company
— ALL68639 8" “Pig” Type, 25-Spline Pinion
ALL68513 ALL68613 8.8" Salisbury Type With 10-Bolt Cover, 30-Spline Pinion
ALL68510 ALL68610 9" 2.893" Carrier Bearing, Stock 28-Spline Pinion Support, Solid Spacer
ALL68511 ALL68611 9" 2.893" Carrier Bearing, Stock 28-Spline Pinion Support, Crush Sleeve
ALL68509 ALL68610 9" 3.062" Carrier Bearing, Stock 28-Spline Pinion Support, Solid Spacer
ALL68512 ALL68611 9" 3.062" Carrier Bearing, Stock 28-Spline Pinion Support, Crush Sleeve
ALL68539 ALL68610 9" 3.062" Carrier Bearing, Daytona 28-Spline Pinion Support, Solid Spacerv
ALL68538 ALL68611 9" 3.062" Carrier Bearing, Daytona 28-Spline Pinion Support, Crush Sleeve
ALL68543 ALL68610 9" 3.250" Carrier Bearing, Daytona 28-Spline Pinion Support, Solid Spacer
ALL68542 ALL68611 9" 3.250" Carrier Bearing, Daytona 28-Spline Pinion Support, Crush Sleeve
ALL68540 — 9" 3.250" Carrier Bearing, MW or Strange 28-Spline Pinion Support, No Spacer Or Crush Sleeve
ALL68541 — 9" 3.250" Carrier Bearing, MW or Strange 35-Spline Pinion Support, No Spacer Or Crush Sleeve
Dana
ALL68533 ALL68633 — Model 44 / 1967-1997
ALL68534 ALL68634 — Model 60 And 61 / 1966-1998

Ring And Pinion Gear Sets
4XDOLW\ GLIIHUHQWLDO FRPSRQHQWV DUH VXLWDEOH IRU UDFH VWUHHW DQG RII URDG XVH /DSSHG LQ PDWFKHG VHWV IRU
TXLHW RSHUDWLRQ
GM 7.5"
6HWV ¿W EROW ZLWK ULQJ JHDU GLD SLQLRQ VWHP DQG
VSOLQH SLQLRQ
Part No. Ratio Tooth Part No. Ratio Tooth
ALL70110* 3.23 42-13 ALL70115 † 3.73 41-11 FORD 9"
ALL70112* 3.42 41-12 ALL70116* 4.10 41-10 6HWV ¿W EROW ZLWK ULQJ JHDU GLD SLQLRQ VWHP DQG
ALL70113 † 3.42 41-12 ALL70117 † 4.10 41-10 VSOLQH SLQLRQ
ALL70114* 3.73 41-11 ALL70118* 4.56 41-9 Part No. Ratio Tooth Part No. Ratio Tooth
* Set includes standard width ring gear for use with 3.23 and numerically ALL70010 3.50 35-10 ALL70028 5.14 36-7
higher ratio carriers or when using 3.08 and numerically lower ratio carriers ALL70012 3.70 37-10 ALL70030 5.29 37-7
and ALL70100 spacer. ALL70014 3.89 35-9 ALL70032 5.43 38-7
† Set includes thick ring gear for use with 3.08 and numerically lower ratio ALL70016 4.11 37-9 ALL70034 5.67 34-6
carriers. ALL70018 4.30 39-9 ALL70036 5.83 35-6
ALL70020 4.56 41-9 ALL70038 6.00 30-5
GM 8.5" ALL70022 4.71 33-7 ALL70040 6.20 31-5
6HWV ¿W EROW ZLWK ULQJ JHDU GLD SLQLRQ VWHP DQG ALL70024 4.86 34-7 ALL70042 6.33 38-6
VSOLQH SLQLRQ ALL70026 5.00 30-6 ALL70044 6.50 39-6
Part No. Ratio Tooth Part No. Ratio Tooth
ALL70120 3.08 40-13 ALL70126 4.10 41-10
ALL70122 3.42 41-12 ALL70128 4.56 41-9
ALL70124 3.73 41-11
