CAVITE STATE UNIVERSITY
T3 CAMPUS
Department of Information Technology ITEC 90 – Network Fundamentals

Changing Router Username and Password
Follow the step-by-step procedures on how to change the router username and
password.

1. Open a browser.
2. Type the default IP Address to the search bar (192.168.0.1).
3. Router Log-in form will be displayed.
4. Enter username and password then click “Login”.
5. Different options will be displayed.
6. Click “System Tools”.
7. Then click “Password”.
8. Enter user name & old password then enter also the new username and password.
9. Then click “Save” and the Router Username and Password is now changed.

Note: Check the PowerPoint presentations on how to change router username and password
for detailed illustration.

Changing Wireless Name and Security Key
Follow the step-by-step procedures on how to change the wireless name and security
key. The difference is that the previous topic is on the administrative privileges of accessing
the router itself while this is when you connect wirelessly; what name appears on your phone's
wi-fi connection options.

1. Open a browser.
2. Type the default IP Address to the search bar (192.168.0.1).
3. Router Log-in form will be displayed.
4. Enter username and password then click “Login”.
5. Different options will be displayed.
6. Click “Wireless” then “Wireless Settings”
7. Enter your desired Wireless Network Name.
8. Click “Save”.
9. Click “Wireless Security”.
10. Enter your desired Wireless Password.
11. Click “Save”.

Note: Check the PowerPoint presentations on how to change wireless and security key for
detailed illustration.

MAC Address Reservation
Follow the step-by-step procedures on how to configure the MAC Address Reserve.
This is done when you want to reserve specific devices to connect exclusively to the router,
no matter how much limit you put into wireless devices to connect, for example. Each device
has a MAC Address so this means that you are reserving these devices. Most of the time
these devices are your own or the family's. So, no matter how many neighbors or friends
connect to your router, and you've limited to only 5, for example, your devices will still connect.

1. Open a browser.
2. Type the default IP Address to the search bar (192.168.0.1).
3. Router Log-in form will be displayed.
4. Enter username and password then click “Login”.
5. Different options will be displayed.
6. Click “DHCP”, then “DHCP Settings”
7. Click on “Address Reservation” then click “Add New”.
8. Enter the MAC Address of the device you want to reserve.
9. Enter also the Reserve IP Address that you want to give to the specific device.

50
