AVAILABLE PROBES / SONDES DISPONIBLES
Convex array: Convex array:
C361-2 C341-2
STANDARD PROBE

Micro-convex array: Linear array:
C611-2 L761-2

Endovaginal: Endorectal:
E611-2 E741-2

Convex array: Micro-convex array:
C363-2 C421-2

Linear array: Linear array:
L741-2 L743-2

DUS 60
DIGITAL ULTRASONIC DIAGNOSTIC IMAGING SYSTEM
GB
DUS 60 is an impressive new compact ultrasound system providing superb value and best-in-class quality across a wide range of applications, with enhanced support of PW imaging to meet the highest diagnostic requirement.
Phased inversion harmonic compound imaging. Multi-beam forming. Synthetic aperture. PW Doppler function. 5-frequency broadband transducer selection for wide clinical applications including: abdomen, obstetrics, gynecology,
small parts, orthopedics, cardiology, peripheral vessels and urology. Compact, lightweight design, two hours of battery-powered operation (battery on demand). Large capacity integrated hard disk expands data storage.
ECHOGRAPHE
F
DUS 60 est un appareil à ultrasons impressionnant et de grande qualité. Il offre une large gamme d'applications et associé à la technologie doppler il sera conforme aux exigences élevées en matière de diagnostic.
Imagerie harmonique avec inversion de phase, multi-faisceaux, synthèse d’ouverture, mode doppler pulsé. Transducteurs larges bandes 5 fréquences accessibles via le panneau de commandes. Domaines d’application : abdominal,
obstétrique, gynécologie, musculo-squelettique, vasculaire, cardiologie, urologie. Design : compact et léger. Batterie 2h d’autonomie (batterie en option). Ecran LCD-TFT 12,1”. Disque dur intégré de grande capacité augmente le
stockage des données.
GENERAL FEATURES MEASUREMENT AND CALCULATION
Imaging mode: B, 2B, 4B, B+M, M and PW B-mode Distance, circumference, area, volume, ratio
Gray scales: 256 stenosis %, histogram and angle
Display: 12.1"TFT/LCD M-mode Distance, time, slope and heart rate
Transducer frequency: 2.0-10.0MHZ D-mode Time, heart rate, velocity, acceleration, trace and RI
Transducer connectror: 2 standard Software packages: General, obstetric, small part, gynecology,
Beam-forming: Phased inversion harmonic compound imaging orthopedics, cardiology, peripheral vessels and urology
Multi-Beam-Forming
Synyhetic aperture DIPLAY
Dynamic receving focusing Date, time, probe frequency, frame rate, patient name, patient ID, hospital name,
Real-time dynamic aperture measurement values, body marks, annotation, probe position, full-image-region edit
Dynamic frequency scanning
Dynamic apodization STANDARD CONFIGURATION
Scanning angle: Up to 152 degree (depending on transducers) DUS 60 main unit
Scanning depth (mm): From 19 to 324 (depending on transducers) 12.1"TFT LCD monitor
FUNCTIONS 2 transducer connectors
Cine loop: 256 frames bidirectional cine-loop Power doppler imaging
multi-pseudo-color imaging
Zoom: x1.0, x1.2, x1.4, x1.6, x2.0, x2.4, x3.0, x4.0 in distance 256 frames cine loop memory
panoramic zoom in real-time and frozen condiction 504MB built-in image storage
Storage media: 2 USB port
Built-in image archive: 504MB built-in image storage Measurement and calculation software packages
Body mark: > 130 types Convex array transducer C361-2 (2.5, 3.5, 4.5, H2.5, H2.7MHz)
Tranducer auto-detection Laser printer
OTHERS
peripheral port: S-video output: 1 / Video output: 1 / ON DEMAND / SUR DEMANDE
WGA output: 1 / USB port: 2 / Ethernet port: 1 DUS 60Trolley Trolley for DUS 60
Remote control: 1 / Footswich port: 1 Convex array transducer: C341-2 (3.0. 4.0, 5.0, H2.5, H2.7MHz)
power supply: 100V-240V ~ 50Hz / 60Hz Convex array transducer: C363-2 (2.5. 3.5, 4.5, H2.5, H2.7MHz)
Lithium battery Continuous working for 2 hours Micro-convex array tranducer: C611-2 (5.5, 6.5, 7.5, H4.5, H4.7MHz)
Dimensions: 220mm(L) x 330mm (W) x 320mm (H) Micro-convex array tranducer: C421-2 (3.0, 4.0, 5.0, H2.5, H2.7MHz)
Net weight: 7.1Kg Linear array tranducer: L741-2 (6.5, 7.5, 8.5, H4.5, H4.7MHz)
IMMAGING PROCESSING Linear array tranducer: L761-2 (6.5, 7.5, 8.5, H4.5, H4.7MHz)
L743-2 (6.5, 7.5, 8.5, H4.5, H4.7MHz)
Linear array tranducer:
Pre-processing Dynamic range / Frame persist / Line average / Endovaginal tranducer: E611-2 (6.5, 7.5, 8.5, H4.5, H4.7MHz)
Edge enhance / Gain / Smooth / AGC / Endorectal tranducer: E741-2 (6.5, 7.5, 8.5, H4.5, H4.7MHz)
8-segment TGC adjustment / IP (imaging process)
Post-processing: Gray map / eSRI / Pseudo-color / Black-white ON DEMAND / SUR DEMANDE
reverse / Left-Right reverse / Up-Down reverse /
Image rotation at 270 degree interval
