MATERIAL HANDLING LIFtInG BOOMS

LIFt MaSteR BOOMS
Unique performance, convenience and safety features
are built into every Lift Master Boom. Fabricated from
structural steel with welding to meet AWS creates a rugged
ECONOMY BOOM and durable boom that will provide long term service.
model LM-EBT Telescopic units extend to 144" and come with an infinitely
adjustable locking screw (exception LM-OBT which
features a spring loaded detent). Fork pockets for 4,000
ORBITING BOOM lbs. capacity models measure 7½"W x 2½"H usable on 24"
model LM-OBT centers. Usable fork pockets are 7¼"W x 2¼"H for 6,000
and 8,000 lbs. capacity option. A 36" safety chain secures
LIFT MASTER BOOM the boom to the fork truck for safe operation. Each unit
model LM-1T includes two lifting hooks.
MODEL OVERALL CAPACITY NET WT.
NUMBER DESCRIPTION HEIGHT (POUNDS) (LBS.)
LM-1t TELESCOPING LIFT MASTER ONE 28" 4,000 424
LM-OBt ORBIT TELESCOPING BOOM 28" 4,000 500
LM-HRt HIGH-RISE TELESCOPING BOOM 70" 4,000 875
LM-eBt TELESCOPING ECONOMY BOOM 11" 4,000 370
LM-1nt NON-TELESCOPING LIFT MASTER BOOM 28" 4,000 403
LM-OBnt NON-TELESCOPING ORBIT BOOM 28" 4,000 558
HIGH-RISE BOOM LM-HRnt NON-TELESCOPING HIGH-RISE BOOM 70" 4,000 627
model LM-HRT LM-eBnt NON-TELESCOPING ECONOMY BOOM 11" 4,000 431
DC-25/FC-70
MODEL NET WT.
NUMBER DESCRIPTION (LBS.)
LM-6 6,000 POUND CAPACITY UPGRADE 70
8,000 POUND CAPACITY UPGRADE (AVAILABLE ON LM-EBT AND
LM-8 190
LM-1T)
LM-8-OBt 8,000 POUND CAPACITY UPGRADE (AVAILABLE ON LM-OBT,) 234
LM-FP LARGER FORK POCKETS 8¼"W x 4¼"H (INSIDE DIMENSION) 23
LIFT MASTER BOOM
model LM-1T-8

POLyeSteR LIFtInG SLInGS - DOUBLe PLy

For medium to heavy-duty lifting, these double-ply lifting slings are the practical, economical answer
to many lifting problems. TYPE III style, with fabric ends, has flat tapered eyes at both ends and can
be used for all hitch types. Double capacity when used basket-style. Reduce capacity 20% when used
chocker-style. These slings meet DIN-EN 1492-1, ANSI standard B30.9 and OSHA requirements.
MODEL STRAIGHT LIFT WIDTH COLOR
NUMBER CAPACITY (LBS.) (INCHES) CODE
MetaL enDS - tyPe 1
(SL-2-F-(length 2,000 1 PURPLE
(SL-4-F-(length 4,000 2 GREEN
(SL-6-F-(length 6,000 3 YELLOW
ReInFORCeD FaBRIC LOOP enDS - tyPe -III
(SL-2-F-(length 2,000 1 PURPLE
(SL-4-F-(length 4,000 2 GREEN
(SL-6-F-(length 6,000 3 YELLOW
DC-25/UPS/FC-70

SWIVeL HOOKS WItH SHaCKLe

Easily connects to Hoisting Hooks, Hook Plates or Booms. Variety of capacities available.
Forged steel construction.

MODEL OVERALL OVERALL THROAT CAPACITY NET WT.
NUMBER HEIGHT WIDTH OPENING (POUNDS) (LBS.)
HOOK-4 10" 3½" 7/8" 4,000 4
HOOK-6 12" 4¾" 1-3/8" 6,000 7
HOOK-10 14½" 6½" 1-7/8" 10,000 9
DC-25/UPS/FC-70
