Page 128 - HILTI

Cutting, Sawing, and Grinding

Diamond cutting disc SP-T Universal Diamond cup wheel P universal

Key applications and advantages Key applications and advantages
■ Super performance line - turbo, continous-rim segment design ■ Grinding concrete and screed
■ Cutting, resizing and reshaping a wide range of mineral con- ■ Extended lifetime – made to outlast
struction materials, especially concrete, masonry and natural ■ Good surface finish
stone
■ Great productivity gain in everyday cutting applications on
mineral materials
■ For use with all Hilti hand-held diamond cutting tools including
angle grinders, electric cutters and gas saws
■ Long lifetime in universal use on a wide range of materials
thanks to large diamond segments and special bond Ordering designation Disc diameter Arbour Colour Number of segments Package contents Sales pack Item number
quantity
DG-CW 100/20 P (2) 100 mm 20 mm Grey 8 2 pc 2164630
Ordering designation Arbour Blade thickness Sales pack quantity Item number DG-CW 115/22.2 P (2) 115 mm 22.23 mm Grey 8 2 pc 2163738
SP-T 115/22 univ 22.23 mm 1.4 mm 1 pc 2117882 DG-CW 125/22.2 P (2) 125 mm 22.23 mm Grey 9 2 pc 2163739 Cutting, Sawing and Grinding
SP-T 125/22 univ 22.23 mm 1.4 mm 1 pc 2117884 DG-CW 180/22.2 P (2) 175 mm 22.23 mm Grey 11 2 pc 2163740
SP-T 180/22 univ 22.23 mm 1.6 mm 1 pc 2117888
SP-T 230/22 univ 22.23 mm 1.6 mm 1 pc 2117890

Diamond cup wheel SPX Epoxy
Diamond cup wheel SPX Universal
Key applications and advantages
Key applications and advantages ■ Removing polyurethane, adhesive, paint, epoxy and acrylic
coatings
■ Roughening and levelling concrete, screed and natural stone
■ PCD cutters for fast coating removal
■ Long life
■ Maximum coating removal speed on plastic and sticky coatings
■ Fast material removal

Ordering designation Disc diameter Arbour Colour Number of segments Sales pack Item number
quantity
Ordering designation Disc diameter Arbour Colour Number of segments Sales pack Item number SPX epoxy 125/5” 125 mm 22.2 mm Dark grey RAL 7030 6 1 pc 2163725
quantity
SPX epoxy 150/6” 150 mm 19 mm Dark grey RAL 7030 6 1 pc 2163726
SPX 115/4.5” univ 115 mm 22.2 mm Red 7 2 pc 2163564
SPX 125/5” univ 125 mm 22.2 mm Red 7 2 pc 2163565
SPX 150/6” univ 150 mm 19 mm Red 8 2 pc 2163567
SPX 180/7” univ 180 mm 22.2 mm Red 8 2 pc 2163569

Diamond cup wheel SPX Abrasive
Key applications and advantages
■ High productivity
■ Roughening and leveling abrasive material
■ Unique pin holes for better segment cooling and thus faster
Diamond cup wheel SP Universal
progress and longer life
Key applications and advantages ■ Maixmum lifetime on abrasive materials
■ Fast material removal ■ High concentration of high-quality diamonds
■ Roughening
■ Maximum coating removal speed on plastic and sticky coatings
Ordering designation Disc diameter Arbour Colour Number of segments Sales pack Item number
quantity
SPX abrasive 125/5” 125 mm 22.2 mm White 8 1 pc 2163725
SPX abrasive 150/6” 150 mm 19 mm White 8 1 pc 2163728

Ordering designation Disc diameter Arbour Colour Number of segments Sales pack Item number
quantity
DG-CW 115/4.5” SP 115 mm 22.2 mm Black 6 1 pc 2163729
DG-CW 125/5” SP 125 mm 22.2 mm Black 6 1 pc 2163730
DG-CW 150/6” SP 150 mm 19 mm Black Black 8 1 pc 2163733
DG-CW 180/7” SP 180 mm 22.2 mm Black 8 1 pc 2163736

118 Visit the local website for more information on products and services. www.hilti.group 119
