Direct Fastening

Cordless drill SF BT
Key applications and advantages
■ Drilling highly accurate holes for X-BT, X-BT-ER and X-BT-MF
fasteners
■ Compact and lightweight
■ Integrated trigger lock for safety

Powder-actuated tool DX 351-BTG Ordering designation Package contents Sales pack Item number
quantity
Key applications and advantages Technical data SF BT 22-A 1x Cordless drill SF BT 22-A 1 pc 2123719
■ Fastening gratings using the X-BT M8 Power source type Hilti 27 cal. cartridges
fastener for powder-actuated
tools
■ Fastening to coated steel in corrosive
environments using 8 mm threaded Power (max.) 85 J
studs Fastener length 21 - 21 mm
■ A quick, easy and reliable fastening range DX Clean-Tec cartridges for the X-BT system 6.8/11 M10 brown
solution that eliminates the need for Fastener intake Threaded stud
subsequent finishing Key applications and advantages
Weight 2.36 kg
■ Ideal for use on high-strength coated ■ Driving X-BT threaded studs on steel
steel, 8 mm or thicker Dimensions 431 x 56 x 164 mm ■ Free of lead and other heavy metals
(LxWxH)
■ Greater efficiency: numbered strips ensure no cartridges are
Max. fastener driv- 700 / h
wasted
ing rate
Base materials Steel Ordering designation Sales pack Item number
quantity
Certificates CE
6.8/11 M10 STD brown 100 pc 412689
Operating tempera- -15 - 45 °C
ture range
1#5 Direct Direct |Fastening Fastening

4

Stepped drill bit TX-BT
Ordering designation Package contents Sales pack Item number
quantity
DX 351 BT G 1x Piston X-351 BT P G, 1x Fastener guide X-351 BT FG G assy, 1x Cleaning kit DX 351, 1x Case 1 pc 377624 Key applications and advantages
■ Pre-drilling for X-BT fastenings
■ The step ensures correct hole depth
Ordering designation Length Diameter Sales pack Item number
quantity
TX-BT 4/7-80 0 m 4 mm 1 pc 377079
TX-BT 4/7-110 0 m 4 mm 1 pc 377080
Powder-actuated tool DX 460-GR
Key applications and advantages
■ Fastening gratings to steel structures for all types of buildings
and plants: refineries, chemical plants, offshore platforms, civil
engineering and industrial construction
■ Power plants
Chequer plate fastener (duplex-coated) X-FCP-F
■ Warehouses
■ Fast, economical and convenient: up to 120 grating fastenings Key applications and advantages
per hour by one user
■ Fastening checker plate in mildly corrosive environments (not
■ Total mobility and complete independence from electrical power for off-shore use!)
supplies (no cables)
■ Fastening height of 5 - 13 mm
Ordering designation Package contents Sales pack Item number ■ Duplex-coated disc
quantity
■ Locking tabs on the disc prevent working loose
DX 460 GR 1x Piston X-5-460-PGR, 1x Fastener guide X-5-460-FGR assy, 1x Cleaning kit DX 460, 1x Case 1 pc 304394
Ordering designation Diameter Grating height Sales pack Item number
quantity
X-FCP-F 5/10 45 mm 5 - 13 mm 200 pc 308859

www.hilti.group
