Aluminum Suspension Tubes
3/4" Solid Rod End ALL58112
Solid rod ends are built using 1045 steel and are
then chrome plated for added wear resistance. End has a body width of 7/8" to match the width of stan- dard rod ends.
Bolt Center Caps ALL10678 Caps slip over the head of standard
1/2" bolts to accurately measure the
center-to-center length of installed sus-
pension tube assemblies. Machined step
secures the end of a standard tape mea-
sure for easy reading of the length to the center of the opposite cap. Caps feature a built-in O-ring that allows the cap to swivel on the bolt head and keeps it from falling off. Package of 2.
Jam Nuts - Standard Hex
Allstar jam nuts have many uses. Great for locking rod ends tightly on suspension tubes or rack and pinion steering units. Package of 4, unless noted.
Swaged 1-1/8" O.D. tubes are built from .156" wall tubing
and have 5/8" RH and LH threads.
SUSPENSION
Length
5/8" Thread Black Anodized
5/8" Thread Polished Aluminum
10"
ALL56806-10
ALL56807-10
11"
ALL56806-11
ALL56807-11
12"
ALL56806-12
ALL56807-12
12-1/2"
ALL56806-125
ALL56807-125
13"
ALL56806-13
ALL56807-13
13-1/2"
ALL56806-135
ALL56807-135
14"
ALL56806-14
ALL56807-14
14-1/2"
ALL56806-145
ALL56807-145
15"
ALL56806-15
ALL56807-15
16"
ALL56806-16
ALL56807-16
17"
ALL56806-17
ALL56807-17
18"
ALL56806-18
ALL56807-18
18-1/2"
ALL56806-185
ALL56807-185
19"
ALL56806-19
ALL56807-19
19-1/2"
ALL56806-195
ALL56807-195
20"
ALL56806-20
ALL56807-20
20-1/2"
ALL56806-205
ALL56807-205
21"
ALL56806-21
ALL56807-21
21-1/2"
ALL56806-215
ALL56807-215
22"
ALL56806-22
ALL56807-22
22-1/2"
ALL56806-225
ALL56807-225
23"
ALL56806-23
ALL56807-23
23-1/2"
ALL56806-235
ALL56807-235
24"
ALL56806-24
ALL56807-24
24-1/2"
ALL56806-245
ALL56807-245
Size Steel
Aluminum
1/4"-28 RH
ALL18250
—
1/4"-28 LH
ALL18251
—
5/16"-24 RH
ALL18252
—
5/16"-24 LH
ALL18253
—
3/8"-24RH
ALL18254
ALL18274
3/8"-24 LH
ALL18255
ALL18275
7/16"-20 RH
ALL18256
ALL18276
7/16"-20 LH
ALL18257
ALL18277
1/2"-20 RH
ALL18258
ALL18278
1/2"-20 LH
ALL18259
ALL18279
5/8"-18 RH
ALL18260
ALL18280
5/8"-18 LH
ALL18261
ALL18281
3/4"-16 RH
ALL18262
ALL18282
3/4"-16 LH
ALL18263
ALL18283
3/4"-10 RH
ALL18264†‡
—
7/8"-9 RH
ALL18266† (Sway Bar Adj. Nut)
—
1"-8 RH
ALL56110† (Jack Bolt Nut)
—
Rod Ends
Two-piece spherical rod ends have a pivoting steel ball and are sold each.
Bore x Thread
RH Male
LH Male
RH Female
Strength
Standard Series Steel
1/4" x 1/4"-28
ALL58004
ALL58014
ALL58034
2,835 lbs.
5/16" x 5/16"-24
ALL58005
ALL58015
ALL58035
4,517 lbs.
3/8" x 3/8"-24
ALL58006
ALL58016
ALL58036
6,323 lbs.
1/2" x 1/2"-20
ALL58008
ALL58018
ALL58038
10,046 lbs.
5/8" x 5/8"-18
ALL58010
ALL58020
ALL58040
15,488 lbs.
3/4" x 3/4"-16
ALL58012
ALL58022
ALL58042
15,894 lbs.
3/4" x 3/4"-16‡
ALL58013‡
—
—
15,894 lbs.
Pro Series Steel (Moly) – Black
1/2" x 1/2"-20
ALL58058
ALL58068
—
17,000 lbs.
1/2" x 5/8"-18
ALL58059
ALL58069
—
19,300 lbs.
5/8" x 5/8"-18
ALL58060
ALL58070
—
18,000 lbs.
3/4" x 3/4"-16
ALL58062
ALL58072
—
25,000 lbs.
Pro Series Steel (Moly) – Black (PTFE Lined)
1/2" x 5/8"-18
ALL58079
ALL58084
—
17,650 lbs.
5/8" x 5/8"-18
ALL58080
ALL58085
—
15,200 lbs.
3/4" x 3/4"-16
ALL58082
ALL58086
—
21,400 lbs.
Aluminum – Black
1/2" x 1/2"-20
ALL58088
ALL58098
—
7,700 lbs.
1/2" x 5/8"-18
ALL58089
ALL58099
—
15,000 lbs.
† Sold each.
‡ Commonly used with UBM35-1107, 3/4"-10 jack bolt.
Steel Jam Nut Assortments

each of 1/4"-28, 5/16"-24, 3/8"-24, 7/16"-20, 1/2"-20, 5/8"-18, and 3/4"-16.
Part No.
ALL18290 ALL18291
Description
35 Asst. RH Jam Nuts 35 Asst. LH Jam Nuts
‡ ALL58013 has an oversized hole and is for use with steering shaft tubing.
Heavy-Duty 3/4" Chrome Moly Rod Ends
Jam Nuts - Small Hex
Specialty jam nuts have smaller outside
diameters, allowing smaller wrenches to
be used when changing radius rod lengths.
Example: with 1/2" bolts, the same 3/4" wrench can be used to adjust radius rod or mounting hole locations. Package of 4.
Heavy-duty or often referred to as “Aircraft Style”, these 4130 chrome moly rod ends have larger bodies, making them 30% stronger than standard 3/4" rod ends. These rod ends are commonly used on Panhard bars and lower strut rods.
Thread Size
Wrench Size
Steel
Alum. Black Alum.
129
5/8"-18 RH
3/4"
ALL18292
ALL18296
ALL18286
5/8"-18 LH
3/4"
ALL18293
ALL18297
ALL18287
3/4"-16 RH
15/16"
ALL18294
ALL18298
ALL18288
3/4"-16 LH
15/16"
ALL18295
ALL18299
ALL18289
Length
ALL99314 ALL99315
5/8" Thread Black Anodized
RH Male, 3/4" x 3/4"-16 RH Female, 3/4" x 3/4"-16
ALL99314
ALL99315
