      Racing Brake Rotors
AFCO racing brake rotors are preci- sion machined and double-disc ground     - able Pillar Vane rotors offer increased strength, reduced weight, and improved
Stock Brake Rotors

sanctioning body requirements for modi-       -
Bolt
Part No. Description Thickness Circle Dia.
* Mount with Hybrid caliper brackets AFC40122PL and AFC40122PR.
 Part No.
Description
Thickness
Bolt
Circle Dia.
Weight
 Pillar Vane Rotors
AFC6640100
Flat Rotor
.810"
7"
11.75"
8.2 lbs.
AFC6640104
Slotted Rotor, RH
.810"
7"
11.75"
8.1 lbs.
AFC6640105
Slotted Rotor, LH
.810"
7"
11.75"
8.1 lbs.
AFC6640106
Slotted Rotor, RH
1.25"
7"
11.75"
10.6 lbs.
AFC6640107
Slotted Rotor, LH
1.25"
7"
11.75"
10.6 lbs.
Curved Vane Ultralight Rotors
AFC6640147
Slotted Rotor, LH
.810”
7"
11.75"
—
AFC6640148
Slotted Rotor, RH
.810”
7"
11.75"
—
Straight Vane Rotors
AFC9850-6020
Straight Vane Rotor
1.25"
7"
11.75"
8.9 lbs.
AFC9850-6021
Straight Vane Rotor
.810"
7"
11.75"
8.2 lbs.
AFC9850-6120
Straight/Drilled Rotor
1.25"
7"
11.75"
7.9 lbs.
 AFC9850-6500
GM Metric Rotor, 1979-Up
1.00"
5x5
10.50"
AFC9850-6505*
Hybrid/Pinto/Mustang II Spindle
.813"
5x5
10.13"
AFC9850-6510
Ford Granada, 1975-81
.875"
5x5
11.00"
  Ultralight Brake Rotors
NEW!
                16-vane design reduces weight, yet retains surface support to reduce the      double-disc ground to ensure precise
Rear Brake Rotor Hat NEW! AFC9850-6600

virtually any rear drum brake car to disc
                  patterns and incorporates straight vanes       bracket, and related hardware must be
 Part No.
Description
Thickness
Bolt Circle
Dia.
 AFC6640145
Flat Rotor, LH
.810"
7"
11.75"
AFC6640146
Flat Rotor, RH
.810"
7"
11.75"
    Precision Pinto Spindles
STEVE DORER
Brake Pedal Assemblies NEW! Forged aluminum H-beam pedal assem- blies
upper mount eliminates the possibility of

clevis, and integral bias bearing simplify

industrial grade anti-skid foot pads and
           -
Part No. Description
Pinto spindles are manufactured, pre- cision machined, and CNC blueprinted
Part No.
Description
 AFC100152
Pinto Spindle, Left, 7.5° Pin
AFC100153
Pinto Spindle, Right, 7.5° Pin
AFC100173
Spindles, Pair, 10° Pin, Reamed for AFC20036 Ball Joint NEW!
AFC100174
Spindles, Left, 10° Pin, Reamed for AFC20036 Ball Joint NEW!
AFC100175
Spindles, Right, 10° Pin, Reamed for AFC20036 Ball Joint NEW!
AFC6610000
 AFC6610000
Reverse-Mount Pedal Assembly
AFC6610001
Forward-Mount Pedal Assembly
   Integral Reservoir Master Cylinders

Part No. Description
184 TRACK
CIRCLE 2021-22
 AFC6620010
3/4" Bore Master Cylinder
AFC6620011
7/8" Bore Master Cylinder
AFC6620012
1" Bore Master Cylinder
AFC6690048
Master Cylinder Lid Kit, Includes Metal Lid, Rubber Gasket and Closure Wire NEW!
