ELECTRICAL, GAUGES, & IGNITION
Heat Shrink Tubing
Single-wall tubing is placed
over wiring and electrical
connectors to seal and
strengthen electrical con-
nections. Tubing is pre-cut to
6" and has a 2:1 shrink ratio,
meaning tubing shrinks to approximately half the size when heat is applied using a heat gun or other heat source.
Junction Block ALL76146 Junction block with single 3/8" stud
offers a location to power multiple
accessories from one power supply or
a common place to locate ground wires.
Block features two mounting holes for
30-Amp Circuit Breaker ALL76212 Circuit breaker protects electrical circuits similar to
fuses but will cool and self-reset to maintain
power to critical items such as headlights or
ignition systems. Use circuit breaker to power accessories in a race car and to keep constant
power to ignition. Steel case and mounting
bracket provide durability and ease mounting to
panels. #10-32 threaded stud terminals include nuts and lock washers.
30-Amp Relays
Relays are commonly used to control higher amperage components such as electric fuel pumps, cooling fans or water pumps rated up to 30 amps. Relays allow the use of a lower amp switch to turn on or control a component with a higher amp draw. A connector with a wiring harness and installation instructions are included.
Heat Shrink Assortment Kit
ALL76160
Includes 9 pcs. of 1/8" and 3/16",
6 pcs. of 1/4" and 3 pcs. each of 3/8" and 1/2"
Individual Sizes (Pack of 20)
ALL76162
1/8"
ALL76164
1/4"
Grommet Set ALL18360
Grommets are perfect for protecting wiring and hoses that
pass through panels up to 1/16" (.062") thick. Kit includes
36 grommets (6 of each size: 1/4", 5/16", 3/8", 1/2", 5/8", and
Part No.
Grommet Hole I.D.
Panel Hole I.D.
ALL18362
3/16"
5/16"
ALL18363
1/4"
3/8"
ALL18364
5/16"
7/16"
ALL18365
3/8"
1/2"
ALL18366
1/2"
5/8"
ALL18367
5/8"
7/8"
ALL18368
11/16"
1"
6-Circuit Fuse Block ALL76180 This fuse block is a great power distribu-
tion starting point for up to six individual
circuits which are protected by ATC/ATO
style fuses (sold separately). Block features
a #10 power supply and six 1/4" male spade
terminals for individual circuit connections. Fuse block is rated at 150 amps at 12 volts, maximum of 25 amps per circuit.
Part No.
ALL76186 ALL76188
Description
Standard Relay Weatherproof Relay
ALL11041
Fuse Terminals
Fuses not included.
Brake Pressure Safety Switch
ALL76255
Brake pressure switch is wired into the
ignition system and kills power to ignition when
a sudden spike in brake pressure is sensed in
the event of an accident or emergency. Switch
has an adjustable cut-off pressure from 700-1900 PSI and resets automatically when brakes are released. A weatherproof cover protects the inner adjustment screw and seals the 18" long pigtail leads. 1/8"NPT male threads.
Terminals attach to cartridge-
style fuses installed in fuse blocks
to create an additional circuit to power ac- cessories. Terminals slide over the protected leg or “fused” side (side of fuse block that does not have power when fuse is removed) of the fuse. Package of 5.
ALL76091
Part No.
ALL76090 ALL76091
ALL76090
Mini Fuse Style Terminal ATC/ATO Fuse Style Terminal
Battery Boxes
Universal, lightweight steel battery boxes may be welded or bolted to the frame. Boxes are available in two siz- es and include hold-down hardware.
Description
Buss Bars
Part No.
ALL76100 ALL76101
Description
Full Size, 12" Wide x 7-1/4" Deep Short Style, 10" Wide x 7-1/4" Deep
ALL76100
ALL76103
47
Buss bars create a remote power
source for powering multiple acces-
sories. Bar features a 1/4” power sup-
ply stud and 12 separate #8 connec-
tions. Insulated base measures 5-1/4”
x 1-1/8” wide and can be mounted
with two #10 (3/16”) fasteners. Bars
include a removable protective cover and power supply boot. Protective covers are sold separately.
Bolt-On Battery Boxes
Battery box has multiple 1/2"
mounting holes to bolt box directly to
Box can also be fastened to round tubing using clamp-on ballast brackets. Construct- ed of 13-gauge steel, measures 11" wide x 7" deep and includes 3/8" battery hold down hardware.
Part No.
Description
ALL76170
Red Buss Bar Kit
ALL76171
Replacement Red Protective Covers
ALL76172
Black Buss Bar Kit
ALL76173
Replacement Black Protective Covers
Part No.
ALL76102 ALL76103
