Dry Sump Oil Tanks
prevents oil aeration while helping to maintain a tall column of oil over the pick-up. Easily disassembled and tops can be rotated for easy placement of
Remote Breather Cans
Mounting clamp is included.
Part No.
PTR08-0005* PTR08-0007* PTR08-0008* PTR08-0009† PTR08-0010† PTR08-0011† PTR08-0013 PTR08-0014 PTR08-0025* PTR08-0110 PTR08-0112
Description
2 Gal. Single Scavenge Inlet, 19.5" Ht. x 6" Dia. 2.5 Gal. Single Scavenge Inlet, 24" Ht. x 6" Dia. 2.5 Gal. Dual Scavenge Inlet, 24" Ht. x 6" Dia.
3 Gal. Single Scavenge Inlet, 16" Ht. x 9" Dia.
3 Gal. Dual Scavenge Inlet, 16" Ht. x 9” Dia.
4 Gal. Single Scavenge Inlet, 19" Ht. x 9" Dia.
5 Gal. Single Scavenge Inlet, 22" Ht. x 9" Dia.NEW! 5 Gal. Dual Scavenge Inlet, 22" Ht. x 9" Dia. NEW! Similar to PTR08-0005 with -12AN Male Fittings Replacement O-Ring for 6" Dia. Tanks Replacement Viton O-Ring for 9" Dia. Tanks
Part No.
PTR08-0400 PTR08-0410
Description
Spun Aluminum Tank,
(2) -12AN Female Ports, and (1) Drain Plug
Spun Aluminum 3" Dia. Tank, Designed to Breathe Oil Tank and
Rear End, (1) -12AN Male Fitting, (1) -8AN Male Fitting, and Quick Drain Valve
* Use Mount Bracket PTR08-0100. † Use Mount Bracket PTR08-0101.
Dirt Late Model Tank
back pressure in the return lines. Easily adapted
Oil Tank Heaters
Pre-heating of dry or wet sump systems on a race engine ensures increased horsepower and good lub- rication upon initial start-up. Immer- pre-heating and only requires weld- ing a threaded bung into the tank. Wraparound styles can be glued to the outside of the tank or pan.
Part No.
PTR08-9016† PTR08-9018† PTR19-5100
Description
4-Gallon Dry Sump Tank with Filter 5-Gallon Dry Sump Tank with Filter Replacement Filter
One-Way Valve Pop Off
PTR08-0450
Breather assembly is installed in valve cover on engine’s running crankcase in vacuum condition. Valve seals engine from air entering engine, but opens in the event of crankcase pressure, allowing
weld to aluminum valve cover.
Screw-In Breather PTR08-0415
† Use Mount Bracket PTR08-0101.
Dry Sump Oil Tank Mounting Brackets
Mounting brackets are machined from billet aluminum and include EPDM rubber-lined stainless steel straps. Sold in pairs.
Part No.
PTR08-0100 PTR08-0101
PTR08-0106
Description
For 6" Dia. Tanks
For 9" Dia. Tanks
Dirt Late Model Style, use on PTR08-9016, Clamps to 1-1/2" Dia. Tubing
used on valve covers.
Oil Pressure Gauge Fittings
Kinser, gets the oil pressure gauge line up where it is more accessible. Fitting
Part No.
PTR15-1040 PTR15-1041
Lightweight Cap and Bung Assemblies
Billet aluminum cap and bung assemblies are useful when fabricating custom tanks.
Part No.
PTR08-0611 PTR08-0621
Description
Cap and Bung Assembly, 1-7/16" Dia. Cap and Bung Assembly, 3" Dia.
Description
Oil Pressure Gauge Fitting, 90° Oil Pressure Gauge Fitting, Straight
Dry Sump Tank Fittings
Peterson dry sump tank.
Oil Filter Block Off Plates
- lation of wet and dry sump oil pressure lines
aluminum billet and include mounting hardware.
Part No.
PTR08-0501 PTR08-0502 PTR08-0503 PTR08-0504 PTR08-0505 PTR08-0506
Description
-10AN Hose x -12AN Port -12AN Hose x -12AN Port -16AN Hose x -12AN Port -6AN Port Plug (Tank Drain) -12AN Port Plug (Tank Drain) O-Ring Kit, -12AN (5 Per Pack)
Part No.
PTR09-0002 PTR09-0004 PTR09-0011 PTR09-0020
Description
Early Chevy V-8, -12AN Fitting with (1) 3/8"-16 Bolt Mount Chevy Bow Tie Block, -12AN Fitting with (2) 5/16"-18 Bolts Mount Ford V-8 with -12AN Fitting
Replacement Square O-Ring for PTR09-0004
TRACK
CIRCLE 2021-22
611
Part No.
PTR08-0300 PTR08-0301
PTR08-0302 PTR08-0310 PTR08-1300
Description
300-Watt Immersion Style 110-Volt with Detachable Cord Set, Steel and Aluminum 1/2" NPT Weld Bungs
300-Watt Wrap Around Pad, 2" x 15", 110 Volt with Detachable Cord Set, Attaches with Hi-Temp RTV Silicone 400-Watt Wrap Around Pad, 4" x 10", 110 Volt with Detachable Cord Set, Attaches with Hi-Temp RTV Silicone Replacement Cord for PTR08-1300
300-Watt Immersion Style 220-Volt with Detachable Cord Set, Steel and Aluminum 1/2" NPT Weld Bungs
