Page 114 - 2021-22_EngineCatalogAP

DRAG RACING OIL PANS
Drag Racing Competition Wet Sump Oil Pans
Pre-1980 LH Dipstick, 2-Pc. Rear Main Seal
Part No.
Description
Pan Dimensions
Finish
Pickup Std. Vol.
Pickup High Vol.
B & B Performance
BBP91088
7-Qt. Deep Rear Sump, Max 3.875" Stroke, Trap-Door Baffle, Crank Scraper, Uni-Directional Windage Tray,
Kit Incl. Pan Bolts & OP Pickup, Steel
8.00"D
Painted Black
Included
N/A
Canton
CAN13-080
6-Qt. Stock Eliminator & Bracket Racing,
Max 3.875" Stroke, Trap-Door Baffle, Crank Scraper, Screen Windage Tray, Steel
8.00"D x 9.5"L x 7.5"W
Clear Zinc
CAN20-050
CAN20-080, CAN20-082 (Press-in MEL10550ST)
CAN13-082 A
6-Qt. Stock Eliminator & Bracket Racing, Stroker Max 4.00" Stroke, Trap-Doors Baffle, Crank Scraper, Screen Windage Tray, Steel
8.00"D x 9.5"L x 7.5"W
Clear Zinc
CAN20-050
CAN20-080, CAN20-082 (Press-in MEL10550ST)
CAN13-104 B
7-Qt. Power Series, Max 3.875" Stroke,
Oil Recovery Pouch, Trap Door Baffle, Crank Scraper, Windage Tray, Pan Mounted Dipstick, Steel
8.00"D x 9.5"L x 10.5"W
Clear Zinc
CAN20-050
CAN20-080, CAN20-082 (Press-in MEL10550ST)
CAN13-100
8-Qt. "T" Rear Sump, Max 3.875" Stroke, Trap-Door Baffle, Crank Scraper, Screen Windage Tray, Steel
8.50"D x 9.5"L x 10.5"W
Clear Zinc
CAN20-060
CAN20-090, CAN20-095 (MELM155HV)
CAN13-120 C
7-Qt. "T" Rear Sump, Max 3.875" Stroke, Trap-Door Baffle, Crank Scraper, Screen Windage Tray, Steel
7.5"D x 9.5"L x 10.5"W
Clear Zinc
CAN20-010, CAN20-013 (MELM155)
CAN20-020, CAN20-023 (MELM155HV)
Milodon
MIL31167
5-Qt. Full Competition Stepped Sump, Max 4.00" Stroke, Full Length Kickout, Full-Length Louvered Windage Tray, Steel
4.5" Front, 8.250" Rear
Gold Iridite
MIL18316 (MIL18750)
MIL18755 (MIL18755)
MIL31145
7-Qt. Full Sump, Super Comp, Super Gas, Tube Chassis, Max 4.00" Stroke, 2 Trap Doors, Full-Length Louvered Windage Tray, Steel
6" Front, 7.625" Rear
Gold Iridite
MIL18315
MIL18740 (3/4" Inlet)
A With steel rods. B Use CAN20-850 Univ. Dipstick or CAN20-854 Univ. Steel Braided Dipstick. C Requires short oil filter.
Pre-1985, LH & RH Dipstick Blocks
Part No.
Description
Pan Dimensions
Finish
Pickup Std. Vol.
Pickup High Vol.
Pickup BBC Pump
Moroso
MOR21017
7-Qt. Deep Rear Sump, Power Pouch Kickout, Max 4.00" Stroke, Louvered Windage Tray, Steel
4.750" Front, 8.250"Rear
Clear Zinc
MOR24170
MOR24350
MOR24320
MOR21234 †
8-Qt. Super Stock/Bracket, Deep Sump, Incl. Dart & Merlin, Max 4.250" Stroke, Double Power Kickout Design, Wide Main Cap Clearance, Billet End Seals, Full-Length Louvered Windage Tray, (2) -8AN Drain Backs and Dipstick Bung, O-Ring Magnetic Drain Plug, Fabricated Aluminum
8.25"D
Aluminum
MOR24170
MOR24350
N/A
Stef’s
STF1020
6-Qt. Deep Rear Sump, Max 3.875" Stroke, Trap-Door Baffle, PTFE Coated Uni-Directional Windage Screen, Kit Incl. Std. Vol. Oil Pump/Pickup Screen Welded Assm. and Pan Bolts, Fabricated Aluminum
4.5" Front,
8.00" Rear, 10.00" Long
Aluminum
Included
N/A
N/A
STF1020AB
6-Qt. Deep Rear Sump, Stroker Notches, Max 4.125" Stroke, Trap-Door Baffle, PTFE-Coated Uni-Directional Windage Screen, Kit Incl. HV Oil Pump/Pickup Screen Welded Assm. and Pan Bolts, Fabricated Aluminum
4.5" Front,
8.00" Rear, 10.00" Long
Aluminum
N/A
Included
N/A
† For use with 168T flywheel combinations.
