CIRCLE TRACK OIL PANS
“Sportsman” Late Model, Sprint Car,
Competition Circle Track, Wet Sump, Left Turn Oil Pan 1986-Up Blocks, Wet Sump, 1-Piece Rear Main Seal - Cont.
Part No.
Description
Pan Dimension DxLxW
Finish
Pickup Std. Vol.
Pickup High Vol.
Pickup BBC Pump
Champ Pans
CHACP80LTRB
8-Qt. Comp Series, Full-Length Kickout,
4 Trap Doors, Crank Scraper, Removable Louvered Windage Tray, 2 Runners,
Oil Temp Fitting, Oil Check Plug, Steel
8" x 9.5" x 14"
Clear Zinc
N/A
CHA80SB
CHA80BB
CHACP100RB
8-Qt. Comp Series, 6 Trap Doors, 3 Crank Scrapers, 2 Runners, Oil Temp & Check Plug, Steel
7" x 12" x 14"
Clear Zinc
CHA1009SB
CHA100SB
CHA100BB
CHACP100LTRB
8-Qt. Comp Series, 6 Trap Doors, 3 Crank Scrapers, 2 Runners, Removable Louvered Windage Tray, Oil Temp & Check Plug, Steel
7" x 12" x 14"
Clear Zinc
CHA1009SB
CHA100SB
CHA100BB
KEVKO
KEV1091WNRH
7-Qt. Rear Sump, RH Dipstick, 4 Gates, Diverter, Temp Fitting, 1" Inspection Fitting
8" x 9.5" x 13.5"
Zinc Plated
KEV1007
KEV1008, KEV1008-10555
N/A
KEV1092NRH
7-Qt. Rear Sump, RH Dipstick, 6 Gates, Diverter, Crank Scraper, Full Windage Tray, Temp Fitting, 1" Inspection Fitting
8" x 12" x15"
Zinc Plated
KEV1005, KEV1005- 10555
KEV1006, KEV1006-10555
N/A
KEV1096NRH
9-Qt. Box Full-Length Power Pouch RS,
RH Dipstick, 10 Gates, Removable Windage Tray, Oil Control Baffles
7.25" D
Zinc Plated
KEV1003, KEV1003- 10555
KEV1005, KEV1005-10555
N/A
Milodon
MIL31516
7-Qt. Pro Comp Pan, Max 4.00" Stroke,
Trap Door, Quick Release Windage Tray, Screw-in Style Dipstick, 1/2" NPT Temp Bung, Magnetic Drain Plug, Steel
7" D x 12" L
Gold Iridite
MIL18305 (use with MIL 18770 pump)
MIL18750
N/A
Moroso
MOR21315
6-Qt. Rear Sump Power Kick-out,
Max 3.80" Stroke, 5 Trap Doors, Louvered Windage Tray, Oil Level Sight Plug, Steel, Tube Chassis
6.5" D x 14" W
Clear Zinc
MOR24314
MOR24315
N/A
MOR21327
8-Qt. IMCA, Limited Sprint Pan,
Offset Rear Sump, Max 4.125" Stroke, 4-Bolt GM, Dart, Merlin Blocks, 5 Trap Doors, Crank Scraper, Removable Windage Tray, 1" Inspection Bung, Steel
6.5" x 16" x11.5"
Clear Zinc
MOR24314
MOR24315
N/A
Dry Sump Competition Circle Track Oil Pan
Pre-1979 Blocks, LH Dipstick, 2-Piece Rear Main Seal
Part No.
Description
Pan Dimensions
Finish
Canton
CAN12-101
Competition Series Shallow, Crank Scraper, Windage Tray Screen, 1/4" Pickup Trough, (2) -12AN Pick Up Fittings RHS, Steel
4.5" D
Clear Zinc
A Requires an offset aftermarket starter with 153- or 168-tooth flywheel.
