PRO TOURING & ROAD RACE OIL PANS
Ford “FE” Block 332-428
Part No.
Front Sump Canton
CAN15-820
Milodon
MIL31650
Moroso
MOR20608
Rear Sump Canton
CAN15-874
Description
8-Qt. Front "T" Sump Road Race Pan, Diamond 6-Trap Door Baffling, Removable Windage/Anti-Slosh Baffle, 1/2" NPT Temp Bung, Steel
7-Qt. Cobra Kit Car, Mustang, Front "T" Sump, Trap Door Baffling, 1/2" NPT Temp Bung, Max 4.250" Stroker Crankshaft, Steel
8-Qt. Front Kicked-Out Sump, 6-Trap Doors, 2 Baffles, Removable Sump Tray, 1/2" NPT Temp Bung, Steel
8-Qt. Rear "T" Sump, Fox Body Mustangs, Diamond Shape 6-Trap Door Baffling, 1/2" NPT Temp Bung, Pan-Mounted Dipstick Bung, Steel
Pan Depth
6"
6"
6"
6"
Finish
Zinc Plated
Gold Iridate
Clear Zinc
Clear Zinc
Pickup HV Pump
CAN15-821
MIL18515
MOR24608
CAN15-875
FORD “FE” 332-428
OIL FILTER ADAPTERS
CAN22-545 FRDM6880-B50
Filter Block-Offs and Remote Adapters
DER15703
Part No.
Canton
CAN22-545
CAN22-565
CAN22-595
Derale
DER15703 DER25750 DER35703 DER35747
Ford Performance
FRDM6880-B50
Moroso
MOR23682
MOR23693
Perma-Cool
PRM111
PRM181 PRM2791 PRM3791
Peterson
PTR09-0011
Trans-Dapt
TRA1013 TRA1015 TRA1313 TRA3320
WIX24730
Description
WIX
Oil Cooler Sandwich Adapter, Billet Aluminum,
3/4"-16 Filter Threads, 2-5/8" Diameter Gasket, O-Ring Seal, 1-1/4" Thick, (2) 1/2" NPT Oil Ports, Black Anodized Oil Input Sandwich Adapter, Billet Aluminum,
3/4"-16 Filter Threads, 2-5/8" Diameter Gasket, O-Ring Seal, 1-1/4" Thick, (2) 1/2" NPT Oil Ports, Black Anodized Remote Oil Filter Adapter, Billet Aluminum, 90° Rotation, 3/4"-16 Filter Threads,
2-5/8" Diameter Gasket, O-Ring Seal, 1/2" NPT Inlet/Outlet Ports, Hardware Included, Black Anodized
Spin-On Oil Filter Adapter with 1/2" NPT Bottom Ports, 3/4"-16 Threads, 2-1/2 & 2-3/4" O-Ring Dia. Remote Filter Mount, 3/4"-16 Filter Nipple, 3/8" NPT Side Mounts
Oil Filter Adapter/Bypass, Black Powder-Coated Aluminum, 3/4-16" Center Thread -10AN O-Ring Inlet/Outlet Prem. Univ. Oil Filter Adapter with -10AN O-Ring Ports, Std & Metric Filter Adapt. Black PC
Ford V8 90° Rotating Oil Filter Adapter, Use with Motorcraft FL-1A Filter
Univ. 3/4"-16, 90° Billet Oil Filter Adapter, 2-5/8" O-Ring, -10AN Oil Ports Univ. 3/4"-16, Billet Oil Filter Sandwich Adapter, 2-5/8" O-Ring, -10AN Oil Ports
Bypass Adapter, Billet Aluminum, 3/4-16" Center Thread-(2)1/2" NPT Female Ports Sandwich Adapter, Aluminum, 3/4-16" Center Thread-(2)3/8" NPT Female Ports Bypass Adapter, Billet Aluminum, 3/4-16" Center Thread-(4)1/2" NPT Female Ports Bypass Adapter, 3/4-16" Center Thread-(2)1/2" NPT Female Ports, Includes O-Rings and Plugs
“FE” Block 352- 428 Oil Filter Block-Off, -12AN Fitting
Ford Spin-On Oil Filter Bypass Adapter
1957-Up “FE” Ford (Exc. 427) Bolt-On Oil Filter Bypass Adapter Ford V8 Oil Filter Sandwich Adapter
Spin-On Billet Ford Bypass Adapter 3/4"-16 Thread
Bypass Adapter, Billet Aluminum, 3/4-16" Center Thread-(2)1/2" NPT Female Ports
