Page 177 - 2021-22 Auto Performance_Hot Rod and Early Muscle
P. 177
NEW VENDOR
RT Series Carburetors Designed for exceptional
street performance, the RT
Series Carburetors are perfect
for classic muscle cars or
street rods. Manufactured
with vacuum secondaries
and electric chokes, these
pressure forged aluminum
carburetors incorporate the
latest technology in air/fuel
calibrations for great out-of-
the box performance. Available in 600, 650, and 750 cfm
Part No. Description
Billet X-treme
Carburetors
The all-out performance
Billet X-treme Series car-
buretors are constructed with CNC-
machined main bodies, 2 circuit billet metering blocks, features provide a carburetor that is extremely tunable and will work with all common fuels including methanol and ethanol. All Billet X-treme carburetors are manufac- tured without chokes and include 2 port fuel bowls, al- lowing installation on virtually any race vehicle. Available with either vacuum or mechanical-operated secondaries.
Description
Vacuum Secondary
Mechanical Secondary
Part
Part
650 CFM Carb, Titanium Main /Red Metering Blocks/ Black Throttle Body
FSC41650B
FSC41650B-1
750 CFM Carb, Titanium Main /Red Metering Blocks/ Black Throttle Body
FSC41750B
FSC41750B-1
750 CFM Carb, Titanium Main /Red Metering Blocks/ Black Throttle Body, 2-Port X Fuel Bowl
FSC41750BB
FSC41750BB-1
850 CFM Carb, Titanium Main/Red Metering Blocks/ Black Throttle Body, 2-Port X Fuel Bowl
FSC41850B-2
FSC41850B-3
850 CFM Carb, Titanium Main /Red Metering Blocks/ Black Throttle Body, 3-Port Viper Fuel Bowl
FSC41850B-2-V
FSC41850B-3-V
850 CFM Carb, Black Main / Red Metering Blocks/Black Throttle Body, 3-Port Viper Fuel Bowl
FSC41850BB-2
FSC41850BB-3
FSC40600
FSC40650
FSC41750
RT Plus
Carburetors Ideal for the weekend warrior, featuring black
electroplated pressure forged metering blocks and bases.
FSC41600P
600 CFM Square Flange RT Carb, Electric Choke, Side Hung Float, Single Feed Fuel Inlet
650 CFM Square Flange RT Carb, Electric Choke, Side Hung Float, Single Feed Fuel Inlet
750 CFM Square Flange RT Carb, Electric Choke, Center Hung Float, Four Corner Idle, Dual Feed Fuel Inlet
Part
FSC40600M
FSC41600P
FSC41600P-1
FSC41600P-3
FSC41650P-1
FSC41650P-3
FSC41750P-1
FSC41750P-3
RT-X
Carburetors Affordably priced, RT-X caburetors are
ideal for both road and track applications. This fully tunable carbure- tor features red billet metering blocks and a black billet base.
Description
600 CFM, Marine, Electric Choke, Vacuum Secondary
600 CFM, Electric Choke, Vacuum Secondary
600 CFM, Manual Choke, Vacuum Secondary
600 CFM, Manual Choke, Mechanical Secondary
650 CFM, Manual Choke, Vacuum Secondary
650 CFM, Manual Choke, Mechanical Secondary
750 CFM, Manual Choke, Vacuum Secondary
750 CFM, Manual Choke, Mechanical Secondary
750 CFM, Manual Choke, Vacuum Secondary
FSC41850BB-2-V
FSC41850BB-3-V
Adjustable Fuel Log
FSC41650D-3
Part
FSC42750XB
FSC42750XB-1
Description
750 CFM, Mechanical Secondary, Black
750 CFM, Vacuum Secondary, Black
Attractively
black anodized
fuel log features an
adjustable
design to work
with a variety of popular 4BBL carburetors. Fuel log includes a -10AN male inlet, dual 7/8”-20 male outlets and a 3/8” NPT port for a fuel pressure gauge.
Hyper Billet In-Line Fuel Pumps
These high-pressure, high-output,
quiet-running billet aluminum in-line
pumps are designed for fuel injected
or carbureted vehicles with either naturally aspirated or forced induction systems. Compatible with gasoline, diesel, ethanol, and methanol fuels.
Part No.
FSC40104
FSC40105
Description
340 LPH In-Line Pump, Supports Up to 1,000 HP, -8AN ORB Inlet/-6AN ORB Outlet
255 LPH In-Line Pump, Supports Up to 750 HP, -6AN ORB Inlet/-6AN ORB Outlet
2021 HOT ROD AND EARLY MUSCLE
175
