2018 National Home Improvement Estimator, All Rights Reserved                                   Page 140



            Concrete roof tile. Material includes felt, nails, and flashing. Approximately 90 pieces per square.
            Monier Lifetile.
              Shake, slurry color                          R1@4.25    Sq    162.61    164.90     327.51
              Slate, thru color                            R1@4.25    Sq    197.96    164.90     362.86
              Espana, slurry coated                        R1@4.25    Sq    197.96    164.90     362.86
              Monier 2000                                  R1@4.25    Sq    210.08    164.90     374.98
              Vignette                                     R1@4.25    Sq    184.83    164.90     349.73
              Collage                                      R1@4.25    Sq    184.83    164.90     349.73
              Tapestry                                     R1@4.25    Sq    202.00    164.90     366.90
              Split shake                                  R1@4.25    Sq    223.21    164.90     388.11
            Trim tile
              Mansard V-ridge or rake, slurry coated         --@.000  Ea      2.60         --       2.60
              Mansard, ridge or rake, thru color             --@.000  Ea      2.71         --       2.71
              Hipstarters, slurry coated                     --@.000  Ea     22.32         --     22.32
              Hipstarters, thru color                        --@.000  Ea     28.38         --     28.38
            Accessories
              Eave closure or birdstop                     R1@.030    LF      1.53       1.16       2.69
              Hurricane or wind clips                      R1@.030    Ea      0.55       1.16       1.71
              Underlayment or felt                         R1@.050    Sq     19.90       1.94     21.84
              Metal flashing and nails                     R1@.306    Sq     11.51     11.87      23.38
            Pre-formed plastic flashing
              Hip (13" long)                               R1@.020    Ea     39.90       0.78     40.67
              Ridge (39" long)                             R1@.030    Ea     40.70       1.16     41.87
              Anti-ponding foam                            R1@.030    LF      0.35       1.16       1.52
              Batten extenders                             R1@.030    Ea      1.37       1.16       2.54
            Roof loading
              Add to load tile and accessories on roof     R1@.822    Sq         --    31.89      31.89

            Elastomeric Decking and Roofing

            Roof walking deck. Includes cleaning of the existing wood, masonry or coated deck, filling fractures,
            masking adjacent surfaces, primer at .3 gallons per 100 SF, Deckgard elastomeric polyurethane texture
            coat at 1 gallon per 100 square feet, polyurethane top coat at 1 gallon per 100 square feet. Per 100
            square feet (square). Includes the cost of spray equipment.
              Based on 800 SF job                          R1@5.00    Sq     84.94    194.00     278.94

            Urethane spray foam roof. Applied over an existing low-slope urethane roof. Includes cleaning roof
            with a broom and air blast, caulking fractures with polyurethane, masking adjacent surfaces, emulsion
            primer at 2 gallons per 100 SF, 3.0-pound density urethane foam, 20 mil elastomeric acrylic top coat
            covered with 40 pounds of mineral granules per square. Per 100 square feet (square). Includes the cost
            of spray equipment.
              Based on 2,500 SF job                        R1@2.80    Sq    142.41    108.60     251.01

            Fiberglass Roofing

            Fiberglass panels. Nailed or screwed onto wood frame.
            Corrugated, 8', 10', 12' panels, 2-1/2" corrugations, standard colors. Costs include 10% for waste,
              Polycarbonate, 26"-wide panels               BC@.012    SF      1.34       0.48       1.83
              Fiberglass, 26"-wide panels                  BC@.012    SF      1.34       0.48       1.83
              PVC, 26"-wide panels                         BC@.012    SF      0.93       0.48       1.41
            Flat panels, clear, green or white,
              .06" flat sheets, 4' x 8', 10', 12'          BC@.012    SF      1.18       0.48       1.66
              .03" rolls, 24", 36", 48" x 50'              BC@.012    SF      1.26       0.48       1.75
              .037" rolls, 24", 36", 48" x 50'             BC@.012    SF      1.45       0.48       1.94
            Nails, ring shank with rubber washer, 1-3/4" (labor included with panels),
              100 per box (covers 130 SF)                    --@.000  SF      0.08         --       0.08
