2018 National Home Improvement Estimator, All Rights Reserved Page 247

Drywall Bead

Galvanized bullnose corner bead. All-metal galvanized steel reinforcement for protecting external
drywall corners. Rounded 3/4" radius outside corner on 1/2" or 5/8" drywall. Attached with nails or
crimping tool. Finish with USG joint compounds.
3/4" x 8' long DI@.128 Ea 5.08 5.02 10.10
3/4" x 10' long DI@.128 Ea 8.12 5.02 13.14

Plastic bullnose corner bead. For use where smooth or rounded corners are specified. Will not dent
or rust. Paint and drywall mud adhere well. Finish compatible with drywall mud and all paint finishes.
3/4" x 8' DI@.128 Ea 4.16 5.02 9.18

135-degree open-angle bullnose drywall arch. Plastic. For hard-to-do arches. No shiner. Wide
flange.
3/4" x 8' DI@.128 Ea 6.34 5.02 11.36

Bullnose open plastic corner. Used where three exterior corners intersect. Treated for maximum joint
adhesion and rust protection. Wide flange.
3-way DI@.160 Ea 1.04 6.27 7.31

Paper-faced metal bullnose outside corner, tape-on. Smooth, rounded radius outside corner for
1/2" or 5/8" drywall. Paper tape cover is laminated to a rust-resistant metal profile for good adhesion of
joint compound. Held in place with joint compound instead of nails to bond the bead to the drywall
surface. Bead is covered with joint compound.
3/4" x 8' long DI@.128 Ea 3.57 5.02 8.58
9/16" x 13/16" x 10' DI@.160 Ea 2.80 6.27 9.07
11/16" x 15/16" x 8' DI@.216 Ea 3.05 8.47 11.52
1-1/16" x 1-1/16" x 8' DI@.216 Ea 2.96 8.47 11.42
1-1/16" x 1-1/16" x 10' DI@.270 Ea 4.22 10.58 14.80

Galvanized bullnose corner bead. Protects corners from damage with a more rounded edge for
curves. Textured flanges allow for better bonding.
1-1/4" x 8' DI@.128 Ea 1.88 5.02 6.89
1-1/4" x 9' DI@.144 Ea 2.10 5.64 7.74
1-1/4" x 10' DI@.160 Ea 2.10 6.27 8.37

Beadex® paper-faced metal L-shaped tape-on trim. Edge reinforcement for drywall panels where
panels abut other materials such as suspended ceilings, beams, plaster, masonry, concrete, door or
window jambs. Paper tape covering laminated to an L-shaped rust-resistant metal profile provides
excellent adhesion of joint compound, texture and paint. Applied using joint compound instead of nails
to bond trim to the drywall surface. Trim is finished with joint compound. For use with 1/2" drywall.
1/2" x 8' DI@.160 Ea 2.51 6.27 8.78
1/2" x 10' DI@.160 Ea 2.63 6.27 8.90

Paper-faced metal inside corner bead. Tape-on trim used to protect drywall panel assembly edges,
corners and sides. Forms a true, inner (90-degree) corner. No fasteners required, adheres to compound.
Eliminates edge cracking, nail pops and chipping.
8' long DI@.216 Ea 4.22 8.47 12.69

Drywall flex corner bead. For use where curve or arch is formed. Pre-slotted flange allows for perfect
arches. Tapered flanges are perforated and striated for adhesion. No need to tape the flange. Finish is
compatible with drywall mud and all paint finishes.
1-1/4" x 10' DI@.270 Ea 3.71 10.58 14.29
