2018 National Home Improvement Estimator, All Rights Reserved Page 379

Vertical discharge bath fan. Galvanized steel housing, with built-in damper and spin-on white
polymeric grille. Polymeric fan blade and duct connectors. Built-in double steel mounting ears with
keyhole slots. Fits 8" ducts. UL listed. Labor includes setting and connecting only. Add the cost of
wiring and ducting. CFM (cubic feet of air per minute).
60 CFM, 4.0 sones BE@1.00 Ea 54.54 43.64 98.18
180 CFM, 5.0 sones BE@1.00 Ea 109.08 43.64 152.72

Vertical discharge bath fan, NuTone. For 75-square-foot bath. Mounts in ceiling, discharges through
duct to roof or wall. White polymeric grille. Fits 7" round ducts. Housing dimensions: 6-15/16" diameter
x 6-1/2" length. Grille size, 8-11/16" x 9-1/2". UL listed for use in tub/shower when used with GFI branch
circuit wiring. Not recommended for kitchen use. Labor includes setting and connecting only. Add the
cost of wiring and ducting. CFM (cubic feet of air per minute).
70 CFM, 2.5 sones BE@1.00 Ea 62.62 43.64 106.26

Vertical discharge utility fan, NuTone. Mounts in ceiling. Discharges through duct to roof or wall.
Pre-wired motor with plug-in receptacle. Adjustable hanger bars for 16" or 24" on-center joists. Silver
anodized aluminum grille. Fits 7" round ducts. Housing dimensions: 11" diameter x 5-5/8" deep. UL
listed. Labor includes setting and connecting only. Add the cost of wiring and ducting. CFM (cubic feet
of air per minute).
210 CFM, 6.5 sones BE@1.00 Ea 52.72 43.64 96.36

Ceiling or wall bath exhaust fan, NuTone. White polymeric grille. Torsion spring grille mounting
requires no tools. Plug-in, permanently lubricated motor. Centrifugal blower wheel. Rugged, 26 gauge
galvanized steel housing. Keyhole mounting brackets for quick, accurate installation. Tapered,
polymeric duct fitting with built-in backdraft damper. UL listed for use over bathtubs and showers when
connected to a GFCI-protected branch circuit. 120 volts, 0.5 amps, 2.5 sones, 80 CFM (HVI-2100
certified) and 4" round duct. Labor includes setting and connecting only. Add the cost of wiring and
ducting. CFM (cubic feet of air per minute).
80 CFM, 2.5 sones BE@1.00 Ea 76.26 43.64 119.90

Bath exhaust fan, Broan Manufacturing. Aluminum centrifugal blower wheel powered by 4-pole
1,500-RPM low-sound motor. Fits 4" ducts. White polymeric designer grille, torsion spring-mounted.
Housing dimensions: 8" length, 8-1/4" width, 5-3/4" depth. UL listed for use over bathtubs and showers
when connected to a GFCI-protected branch circuit. Labor includes setting and connecting only. Add
the cost of wiring and ducting. CFM (cubic feet of air per minute).
110 CFM, 4.0 sones BE@1.00 Ea 92.52 43.64 136.16

Bath exhaust fan. Pre-wired outlet box for plug-in motor plate, torsion spring-mounted low-profile grille.
Steel housing, damper to eliminate backdrafts. Housing: 9-1/4" x 9-1/2" x 7-5/8". AMCA licensed for air
and sound. UL listed to use over tub or shower enclosure with GFCI-protected branch circuit. HVI
Certified. 4" duct. Labor includes setting and connecting only. Add the cost of wiring and ducting. CFM
(cubic feet of air per minute).
80 CFM, 2.5 sones BE@1.00 Ea 106.05 43.64 149.69
80 CFM, 3.5 sones BE@1.00 Ea 117.16 43.64 160.80
90 CFM, 1.5 sones BE@1.00 Ea 138.37 43.64 182.01
120 CFM, 2.5 sones BE@1.00 Ea 169.68 43.64 213.32
130 CFM, 2.5 sones BE@1.00 Ea 180.79 43.64 224.43

Ultra Silent® low-sound bath fan, Broan Manufacturing. Centrifugal blower. 7-5/8" high housing. UL
listed for use over bathtubs and showers when connected to a GFCI-protected branch circuit. AMCA
licensed for both air and sound. 4" duct. Labor includes setting and connecting only. Add the cost of
wiring and ducting. CFM (cubic feet of air per minute).
80 CFM, 0.6 sones BE@1.00 Ea 129.28 43.64 172.92
110 CFM, 1.5 sones BE@1.00 Ea 165.64 43.64 209.28
