CIRCUIT BREAKER ENCLOSURES
CIRCUIT BREAKER ENCLOSURE Surface mount option for mounting single and double pole circuit breakers FEATURES: • Wire glands included for secure installation of circuit breakers • Accepts A-Series toggle (See Page 311) and A and C-Series Flat Rocker
circuit breakers, LED’s (See Page 308) and Square format labels
for custom configurations (See Page 309). Specifications: 4.92"H x 3.95"W x 4.07"D (124.97 mm x 100.33mm x 103.038mm)
AC SMS SURFACE MOUNT SYSTEM
Panel enclosure for ELCI Main circuit breakers and other large frame devices. Meets ABYC E-11 when used with an ELCI Main circuit breaker and mounted within 10 feet of the shore power inlet. • Models available with ELCI Main circuit breakers for 120V 30A
• Blank apertures for custom breaker loading • Glass filled polycarbonate base • Clear cover allows easy view of circuit breaker status • Overlapping cover for strength and increased gasket protection • Oversized, formed in place seamless PUR gasket • Easily removed stainless steel hinge pin for unobstructed installation • Stainless steel latch secures cover without penetrating the enclosure • Blank circuit positions accommodate Carling TechnologiesTM
Labels, circuit breaker, and LED’s are sold separately
ORDER NO.
738-31310
Mfr. No.
3131
Specifications:
Enclosure Size Exterior Overall Dimensions
Temperature Range Cover Screws and Hardware Mounting Hardware LEDs Installed: Model 3117 2 x green
6.0" x 6.0" x 4.0" 152 mm x 152 mm x 102 mm 7.6" x 7.4" x 4.7" 192 mm x 188 mm x 120 mm -35˚C to 66˚C 10-32 stainless steel 1/4", #12, (6 mm)
ON indicating 120V AC (738-80340) 2 x red Reverse Polarity 120V AC (738-80660)
Model 3120 2 x green ON indicating 240V AC (6806) Labels Included: Model 3117 Source Selection label set - 10 labels
2 x Reverse Polarity, 2 ELCI Panel Voltage ID Model 3120 1 x AC Main, 1 ELCI Panel Voltage ID
Regulatory
IP66 - Protected against powerful water jets when cover is latched. Flammability rating-Per UL 508 Toxicity - Non-toxic, halogen free, RoHS compliant UL Listed and NEMA 4X rated,
NEMA Type 4, 4X, 6, 6P, 12, and 13
A- and C- Series Flat Rocker and ELCI Main circuit breakers • Stainless steel mounting hardware included • Includes waterproof glands • LED lights for back lighting and ON indication
Note: SMS panel enclosures are pre-assembled & ready for wire connections. Customers must select wire & entry or exit locations, drill holes, & install the appropriate glands.
3117
ORDER NO.
738-31170
738-31200
3120
Mfr. No.
3117
3120
Description
Installed Circuit Breakers
2 x ELCI Main 120V 30A, 30mA (3102)
1 x ELCI Main 240V, 50A, 30mA (3093)
For more information see: www.bluesea.com
Glands Included
2 x (3124) 4 x (3125)
2 x (3124) 1 x (3125) 2 x (3126)
120V AC ELCI 30A Dual
ELCI Main + 2 Blank Positions
SPECIAL ORDER ITEM
