USB ACCESSORY PANELS
360 PANEL SYSTEM ACCESSORIES
360 Panel System accessories include innovative modular back covers for AC 360 Panels. ABYC standards mandate isolation of AC and DC components on combination panels. Stackable, screw-down covers protect AC components from coming into contact with tools, personnel, & DC wiring.
360 PANELS - WITH AC DUAL OUTLETS
Provides a 360 Panel System platform for mounting equipment, switching, and monitoring functions. • Suitable for mounting accessories and for pad printing
Dimensions: 4.88"W (123.83 mm) 4.75"H (120.65 mm)
1.00"D (25.40 mm) ORDER NO. Mfr. No. Description
738-14790 1479 120V AC Dual Outlets
WATER-RESISTANT USB ACCESSORY PANELS
Easy to install accessory panels include a 15A circuit breaker switch and pre-wired harness. Panels offer customizable 12V charging and monitoring options. • Pre-wired harness included in all panels for easy installation
• Silicon breaker boots and gasket protects against water ingress • Illuminated Carling Technologies 15A circuit breaker switch allows
the ability to shut off panel preventing parasitic draw • Polycarbonate/ABS panel face is UV-stabilized, flame retardant,
and will not corrode • 12V DC only Regulatory: CE Certfied
IP66 - Protected against powerful water jets
SOCKET & DUAL USB CHARGER PANELS
Integrates DC Sockets & USB Charger with 360 Panel System Dimensions: 4.88"W (123.83 mm)
4.75"H (120.65 mm) 1.50"D (38.10 mm)
ORDER NO.
738-14780
Mfr. No.
1478
738-43630
738-43650
738-43670
Description
12V DC Socket & 12V DC Dual USB Charger
ORDER NO.
738-43630
738-43640
738-43650
738-43660
738-43670
738-43680
738-43690
Mfr. No.
4363
4364
4365
4366
4367
4368
4369
Description
15A Circuit Breaker, 12V Socket, 2.1A Dual USB Charger
15A Circuit Breaker, 2x Blank Apertures
15A Circuit Breaker, 12V Socket 2x 2.1A Dual USB Chargers
15A Circuit Breaker, 12V Socket 2.1A Dual USB Charger, Mini Voltmeter
15A Circuit Breaker, 3x Blank Apertures
12V Socket, 2x 2.1A Dual USB Chargers, Mini Voltmeter
15A Circuit Breaker, 4x Blank Apertures
Width in (mm)
4.94" (125.4mm)
4.94" (125.4mm)
6.61" (168.0mm)
6.61" (168.0mm)
6.61" (168.0mm)
8.29" (210.5mm)
8.29" (210.5mm)
738-43690
Height
2.25" (57.2mm)
2.25" (57.2mm)
2.25" (57.2mm)
2.25" (57.2mm)
2.25" (57.2mm)
2.25" (57.2mm)
2.25" (57.2mm)
738-43640
738-43660
738-43680
Depth in (mm)
2.53" (64.3mm)
Varies based on installed components
2.53" (64.3mm)
2.75" (69.8mm)
Varies based on installed components
2.75" (69.8mm)
Varies based on installed components
FLOYD BELL TURBO SERIES ALARM
Audibly alerts operator
Features:
• Adjustable volume by rotating bezel • Tamper resistant front mounting case • Threaded attachment ring • Fits any 1" round aperture
ORDER NO. Mfr. No.
738-10700 1070
Specifications:
Voltage Nominal Operating Voltage Amperage Max. Operating Amperage Max. Operating
24V DC 5-30V DC 15A DC (socket) 10A DC (plug)
For more information see: www.bluesea.com
