Page 701 - 2025 Parts & Accessories Catalogue
P. 701
WINDSHIELD ACCESSORIES/CLEATS
WINDSHIELD SUPPORT BARS
Used as original equipment on many fine walk-thru windshields. The fittings allow for pivot in almost every direction for easy installation. Mounting screws included. Sold in single units.
WINDSHIELD MALE SNAP ADAPTER
Designed and used for many OEM windshield / canvas applications. Molded nylon insert fits into trim grooves. .200" wide by .500" deep and accepts standard male screw-in snaps. 6 sets of inserts and snaps included. Use to secure cockpit covers, bimini tops, etc. ORDER NO. 111-04070 Mfr. No. 407
HIDDEN HOLD-DOWN FASTENERS
ORDER NO. 101-16320 101-16340 101-16360 101-16380
101-16370 101-16390 101-16410 101-16420
Mfr. No. 1632 1634 1636 1638
1637 1639 1641 1642
Size Finish
Adj. Fittings Nylon Black Nylon Black Nylon Black Nylon Black
Chrome Chrome Chrome Chrome
11" 12" 13" 14"
13" 14" 15" 16"
Powder Coat Powder Coat Powder Coat Powder Coat
Alum. Alum. Alum. Alum.
Anodized Alum. Anodized Alum. Anodized Alum. Anodized Alum.
Complete with nuts and rubber grommets ORDER NO. 111-16070 Mfr. No. 1607
For more information see: www.taylormadeproducts.com
• Quick twist release • Winged head nut • Sold by pairs
ORDER NO. 205-65001
WINDSHIELD HOLDER CLIPS
• Makes installation and removing windshield simple • Base mounts to the boat and the quick twist
fastener passes through the windshield • Great for preventing broken windshields in shipping,
installation and for cleaning
Mfr. No. WSH-1PR-DP
OVAL FOLDING CLEAT W/HIDDEN HEX BOLTS
Investment Cast Stainless 316 - Corrosion Resistant
ORDER NO. Mfr. No. A B C D E 420-41115 041115-1 5" 4-5/8" 1-11/16" 1/2" 2-11/16"
For more information see: www.thmarinesupplies.com
F Finish 1/4"-20 x 2" Hex Bolts Polished
Feature an innovative design incorporating removable hex bolts vs. welded studs making bolt length choices easy for the customer. Incorporates a positive locking feature with audible click into the open/closed positions for easy rigging. Accommodates up to 1⁄2” line. Low profile ergonomic design makes for smooth, sleek appearance when closed, limiting trip hazards. Includes: 2 hex bolts, 2 washers, and 2 nuts per cleat.
OVAL FOLDING CLEAT
Investment Cast Stainless 316 - Corrosion Resistant
ORDER NO. Mfr. No. A B C D E Fastener Finish 420-41125 041125-1 5" 4-5/8" 1-11/16" 1/2" 2-11/16" 1/4"FH Polished
Incorporates a positive locking feature with audible click into the open/closed positions for easy rigging. Accommodates up to 1⁄2” line. Low profile ergonomic design makes for smooth, sleek appearance when closed, limiting trip hazards. Surface mounted: no cut-outs or hole saws required. Installs with two 1⁄4-20 through bolts (not included).
RECTANGULAR FOLDING CLEAT W/HIDDEN HEX BOLTS Investment Cast Stainless 316 - Corrosion Resistant
ORDER NO. 420-41135 420-41136
Mfr. No. 041135-1 041136-1
A 4-9/16" 6-1/16"
B C 4-1/2" 1-11/16"
6" 2-3/16"
D 9/16" 11/16"
E 2-11/16" 3-1/2"
F 1/4"-20 x 2" Hex Bolts 5/16"-18 x 2" Hex Bolts
Finish Polished Polished
Features an innovative design incorporating removable hex bolts vs. welded studs making bolt length choices easy for the customer. Drain opening allows water and debris to pass through, reducing corrosion and wear to cleat. Incorporates a positive locking feature with audible click into the open/closed positions for easy rigging. Accommodates up to 1⁄2” line (4-1/2" cleat) or 5/8" line (6" cleat). Low profile ergonomic design makes for smooth, sleek appearance when closed, limiting trip hazards. Includes: 2 hex bolts, 2 washers, and 2 nuts per cleat.
For more information see: www.sea-dog.com
669
