HYDRAULIC STEERING - PARTS & FITTINGS
HELM PARTS, FITTINGS
Comes with every SeaStar helm. Must be used in all single steering station systems or on uppermost helm in multiple steering stations. ORDER NO. Mfr. No. Description 033-61260 HP6126 Vented Fill Plug (5 PK)
For use on lower station in multi-station systems only. Included with kits HF6007 and HF6010. ORDER NO. Mfr. No. Description 033-54320 HA5432 Non-Vented Fill Plug
This helm service kit is for use with all Baystar and SeaStar helms except: HH5279, HH5280, HH5281, HH5217, HH5224, HH4015, and HH4016. Kit contains: 1 quad ring seal, 1 woodruff key, 1 wheel shaft nut, 1 top plate, 4 nyloc nuts- 1/4" NC and 4 flat washers 1/4".
SEASTAR SERVICE PARTS
HP6126
SERVICE KIT-SEASTAR HELMS
HA5432 HP6032 (A)
ORDER NO. 037-60320
ORDER NO. 037-60320
HS5157 (B, C, D)
HF5548 (E)
Mfr. No. Description HP6032 Helm Service Kit
CYLINDER PARTS
ORDER NO. 034-51570 Replacement front seal kit for SeaStar front mount cylinders except PRO models. (HC5345/HC5347/HC5348/HC5358/HC5343/HC5340/HC5342/HC5365). Includes 2 seal glands, pin wrench and guide tool.
Available separately:
Seal Gland (Mfr. No.724124), Seal Gland Assembly Guide Tool (Mfr .No. 745920), Pin Wrench (Mfr. No.745525). (Includes items B, C & D in illustration.)
ORDER NO. Mfr. No. Description 037-55480 HF5548 Front Mount Cylinder Bleed Fitting 2 Bleed fittings, 2 O-rings and 2 soft caps for HC5345/HC5347/HC5348/HC5358. SeaStar front mount cylinders. (Item E in illustration, caps not shown.)
ORDER NO. Mfr. No. Description 037-55200 HF5520 Cylinder Bleeder Tee Fitting Set Pair of bleeder tee fittings for older-style standard and compact SeaStar front mount cylinders (HC5342/HC5340/HC5365), side mount cylinders (HC5370-3), and splashwell mount cylinders (HC5380-3).
ORDER NO. Mfr. No. Description 037-55210 HF5521 Vertical Bleeder Fitting Set Pair of 90-degree fittings with integrated vertical bleeders for use where clearances are tight.
ORDER NO. Mfr. No. Description 037-55130 HF5513 Bulkhead Fitting Kit 3" Max Single Cylinder. Includes: (x2) Connector Fitting and Nipple; (x2) Street Elbow-3/8" Tube (M), 1⁄4" NPT (F) ...
For more information see: www.dometic.com
Mfr. No. Description HS5157 Front Mount Cylinder Seal Kit
HF5513
