SEAL KITS - HELMS & CYLINDERS
HELMS
DESCRIPTION
Seal Kit, SeaStar Helm
HH5201 / HH5202 / HH5220 / HH5241 /
HH5242 / HH5741 / HH5742 Seal Kit, SeaStar Helm 250V / 275V / 1250V / 1275V Seal Kit, SeaStar Helm
1350 / 1350S
DESCRIPTION
MFR.NO.
HS 5151
HS 5161
HS 5171
ORDER NO. 034-51510
034-51610 034-51710
034-51670
034-51530
FITTING KITS - ADD A 2ND STATION
Note: For NPT Helms Only
DESCRIPTION
Kit to add a 2nd station or autopilot to an outboard system
Kit to add a 2nd station or autopilot to an inboard or sterndrive system
MFR.NO.
HF5501 HF5502
ORDER NO. 037-55010 037-55020
CYLINDERS
Seal Kit, O/B Cylinder with wrench (“screw-in-end” gland) HC5340 / HC5342 / HC5365 HC5345 HC5347 / HC5348 / HC5358 HC5343 Seal Kit, O/B Cylinder without wrench (“screw-in-end” gland) HC5340 / HC5342 / HC5365 HC5345 HC5347 / HC5348 / HC5358 HC5343 Seal Kit, O/B Cylinder HC 5370 / OEMHC5371 Seal Kit, O/B Cylinder HC 5380 HS 5155 034-51550 Seal Kit, O/B Cylinder HS 5154 034-51540 125 BA/EM, MV,BJ/ATM,EMV (Alum.) Seal Kit, O/B Cylinder 135 BA/EM, MV, BJ/ATM,EMV(Alum.) Seal Kit, O/B Cylinder 150 BA/EM, MV, BJ/ATM,EMV(Alum.) Seal Kit, O/B Cylinder 150-7 BA / STD , TR, TM (BRASS) Seal Kit, O/B Cylinder 175-7 BA / TR, TM (BRASS) Seal Kit, O/B Cylinder 200-7 BA / STD, TR, TM (BRASS)
HS 5157
HS 5167
HS 5153
REMOTE BULKHEAD FITTINGS
ORDER NO. 034-51570
HYDRAULIC STEERING
Part numbers NOT catalogued, but are in stock or superceded.
HS 5155 HS 5156 HS 5182 HS 5183 HS 5184
034-51550 034-51560 034-51820 034-51830 034-51840
DESCRIPTION
Cylinder Rod End Adapter
Adapter Mount
Fill Vent Plug Kit
Bulkhead Fitting Kit – 3⁄4" max., Single Cylinder
Bulkhead Fitting Kit – 3", Max. Single Cylinder
Bulkhead Fitting Kit – 3⁄4" max., Twin Cylinder
Bulkhead Fitting Kit – 3", Max. Twin Cylinder
Capilano Helm Pump – (1275V)
MFR.NO.
HA5424 HA5425 HA5450
HF5512
HF5513
HF5514
HF5515 HH5275
ORDER NO.
033-54240 033-54250 033-54500
037-55120
037-55130
037-55140
037-55150 038-52750
Note: Please call our Technical Department for Hynautic Steering Parts, Cylinders, Reservoir, Reservalves, Helm & Cylinder Seal Kits.
For more information see: www.dometic.com
These remote bulkhead fittings offer boaters a simple solution to cleanly route hoses through the hull while maintaining safety & aesthetics. Available in both single or dual hose applications for ultimate customization. Stainless steel options provide cleaner styling & corrosion resistance while blending in with your boat’s stainless trim. KEY BENEFITS
• Field installable series of products reduces the amount of stocking hose SKUs by allowing the user to install these on a standard hose kit • Split grommet design allows for easy installation onto a hose assembly • Increased inner diameter of plastic base plate simplifies fitting installation by allowing crimped hose fitting to pass through the base plate • Stainless steel cover plates available for both single and dual applications provide cost effective cosmetic upgrade
Kit: Field installed Bulkhead.
039-71000
039-72000
ORDER NO.
039-71000
039-71050
039-72000
039-72050
Mfr. No.
H07100
H07105
H07200
H07205
Description
Single Hose, Stainless, pair
Single Hose, Plastic, pair
Dual Hose, Stainless, each
Dual Hose, Plastic,each
039-71050
039-72050
