MISCELLANEOUS PUMPS & ACCESSORIES
DC PUMP FOR BILGE, DECKWASH & REFUELLING F38B-19 12VOLT Perfect for bilge pumping, deckwash, water circulation, oil and diesel refuelling at dockside service, etc. These pumps may be combined with a vacuum switch for automatic operation. Capacities vary from 14 I/min to 55 I/min, allowing the proper matching of the pump to the application. All motors are heavy duty to provide long service life even under heavy use.
ORDER NO Mfr. No. Pump Body Replacement Seal Impeller
Connection Length Width Height
Hose 1" / 1/2"NPT 180mm / 7"120 mm / 4.72"90 mm / 3.54"
Weight
6.6 lbs
102-472703 10-24727-03 Bronze
09-824P-9 Lip Seal (Order No. 671-00022)
TA3P10-19 MACERATOR PUMP The Johnson TA3P10-19 Macerator Pump takes care of toilet waste, shredding it before it is pumped into or out from the holding tank. CE-approved.
Features:
•Ignition protected motor, conforming with ISO 8846 Marine •Mounting bracket for easy replacement •Extremely energy efficient •Rotary cutter casing of PET (thermoplastic polyester) •Directly connects to sewage tankline or holding tank •Hose Connecting: Inlet 1-1/2" dia. Hose
or 1-1/2" NPT Outlet 1" hose • 1 Year Warranty Motor Impeller Seal Length Width Height
ORDER NO
102-44531
671-10007
Mfr. No. Model No.
10-24453-01 TA3P10-19 12VDC 671-00007 LipSeal 9.06" 4.25" 3.23"
09-45595 Service Rebuild Kit fo TA3P10-19
CM30 - CIRCULATION PUMP - 12V
Port Size: Capacity 0.1 bar
Dry Running: Input Power: Mounting:
16 mm (5/8") 20 I/min (5.3 GPM) (3.4 ft H2O) Max. 30 minutes Max. 14W (CM10) 27W (CM30) Separate universal bracket for flat surfaces
w/ Flexible cord
Pump body: Shaft: Impeller: System Pressure: HoseConnection: Motor:
PPA, (Thermoplastic) Stainless Steel Repl. Impeller 09-46551 PPS, (Thermoplastic) 2,5 bar max 5/8"(dia.16mm) 12V DC enclosed (as per IP67) permanant magnet, ball bearing mounted motor, designed for continuous operation
Dimensions and Weight
ORDER NO. 102-448803 Mfr. No. 10-24488-03 For more information see: www.spxflow.com/johnson-pump-marine
Length: Width: Height: Weight:
Amps (Max)
17"
6.97" - 177mm 2.68" - 2.68mm 3.35" - 85mm 1.3 lbs. - 0.53 kg
SPECIAL ORDER ITEM
Pump Design:
Type: Centrifugal Pump (Flex-Impeller) Liquid: 130˚F (54˚C) Max Dry-Prime: 4 feet (1.21 m) Run Dry: 20 seconds max
Electrical:
Motor: 12V DC Permanent Magnet, Intermittent Duty Protection:Thermal Overload, Automatic Restart
MACERATOR PUMP - 12VDC
Designed specifically for sanitation waste and fish box evacuations. Features a premium impeller design with run-dry capability and includes our seamless shell motor with o-ring sealed end bells and a sealed manual turn key. The unique dual blade and housing construction ensure problem free pumping, providing superior performance in harsh marine environments. Thermally protected and ignition protected.
1 year warranty.
ORDER NO
320-00010
Mfr. No. Model#
3200-001
OEM
3200-000
Voltage
12VDC
Dimensions (Inches)
10.6" x 4.9" x 3.8"
Flow Rate
13 GPM
Port Size
Inlet 1-1/2" Barb/ 1-1/2" NPT Outlet 1" Barb
For more information see: www.shurflo.com
