FIRST LIGHT SEPTEMBER 91

HYBRID PLUS TUBE RINGS
DRIVE The substantial and beautifully machined PLUS (Prima Luce
FOCUSER Universal System) support rings clamp the scope for mounting.
Three pre-threaded M8 female screw-holes and two head-
The hybrid drive focuser recessed non-threaded holes are provided on the top and bottom
combines the qualities of of each ring. This gives excellent flexibility for both mounting the
a Crayford-style focuser scope on a dovetail as well as attaching extra kit on top.
with that of a lockable
rack and pinion. This
produces a fast, smooth
focusing action that won’t
slip with a heavy camera
attached at high angle.
A 1:11 fine-focus knob
ensures you achieve the
accurate focus with ease.

INTEGRATED
),(/'!)/$77(1(5
Short focal length, wide-field
instruments are great for
covering large sky areas,
but are prone to
distortions noticeable
at the edge and
corners of the
imaging field.
This can be a big
ONAXISLOCK problem if you’re
using a camera
The Airy APO 65F has a serious camera connector in the shape with a large sensor.
of the OnAxisLock system. The telescope offers a 2-inch fitting The Airy APO 65F
as standard and a 1.25-inch adaptor is supplied. A locking contains an internal
ring ensures the barrel of attached equipment is held securely field-flattener made
and exactly on the central optical axis of the scope. from FPL-53 glass.
