Standard specification
Dead weight tester Spare parts and tool

Model number P910 P911 Standard accessories Quantity (pcs)
Range Maximum 5 MPa 10 MPa PF ½" 2
Range Minimum 0.05 MPa 0.1 MPa PF ⅜" 1
Minimum unit pressure 0.05 MPa 1 MPa PF ¼" 1
Area of ram ½ cm² ¼ cm² 300 mm wrench 1
Diameter of ram 7.979 mm 5.6420 mm 250 mm wrench 1
0.05 MPa 1 pcs L type union ½" 1
Ram
0.1 MPa 1 pcs Packing for union 10
Dead-weight 0.05 MPa 1 pcs Packing for piston 3
corresponds Dead 0.1 MPa 2 pcs 2 pcs Hammer 1
to (MPa) weight 0.2 MPa 1 pcs 1 pcs Pointer remover 1
0.5 MPa 9 pcs 1 pcs Oil drum 1
1 MPa 9 pcs
Total 5 MPa 10 MPa
Weight 10 kg 10 kg
Tester
Box weight 7.5 kg 7.5 kg
Weight 26 kg 26 kg
Ram
Box weight 2.8 kg 2.8 kg

Main order Ordering information

1. Base model
P910 Dead weight tester (Calibration range: 5 MPa)
P911 Dead weight tester (Calibration range: 10 MPa)

2. Unused character
00000000000

1 2
Sample
P910 00000000000 ordering code

P910.P911_02
