RECOMMENDED TYPES OF PIPES.
3/4” RIGID GALVANIZED, CPVC APPROVED FOR HOT WATER, 3/4” RIGID COPPER OR 3/4 RIGID SS PIPES RECOMMENDED.
IF ANY TYPE OF THICK WALL PLASTIC PIPES IS USED, SIZE IT UP TO AVOID SIGNIFICANT PIPE ID REDUCTION WHICH WOULD NOT
PROVIDE ENOUGH WATER FLOW FOR THE SYSTEM.
DO NOT USE ANY TYPE OF SPIGOT FITTINGS WHICH SHOULD BE INSTALLED INSIDE THE PIPE PORT. IT WILL REDUCE THE INTERNAL
PIPE DIAMETER AND WATER FLOW CORRESPONDINGLY.
